| Categories | Precision Steel Tube |
|---|---|
| Brand Name: | TORICH |
| Model Number: | A524 |
| Certification: | ISO9001 ISO 14001 TS16949 |
| Place of Origin: | zhejiang/China |
| MOQ: | 1Ton |
| Price: | 800-1100 USD/Ton |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 60000 Ton/Tons per Year |
| Delivery Time: | 20-30days upon products |
| Packaging Details: | In bundles or in wooden boxes. |
| Application: | Atmospheric and Lower Temperatures |
| Outer diameter(round): | 8 - 426 mm |
| Thickness: | 1-100mm |
| Standard: | ASTM,DIN,API,GB,JIS |
| Length: | 5.8-12m,or as required., |
| Material: | Low Carbon Steel |
| Grade: | Grade1 |
| Technique: | Hot Rolled,Cold Drawn,Cold Rolled,ERW,welded and seamless steel pipe |
| Company Info. |
| TORICH INTERNATIONAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
ASTM A524 (also designated A524/A524M-21 in its latest revision) defines the standard specification for seamless low-carbon (killed) steel pipe, primarily intended for service at atmospheric and lower temperatures, covering nominal pipe sizes (NPS) from 1/8″ to 26″ with wall thickness per ANSI B36.10
The steel is required to be killed steel, produced via open-hearth, electric-furnace, or basic-oxygen processes. It should follow fine-grain practices, cast as ingots or strand-cast, and can be supplied either hot-finished or cold-drawn depending on size
| Element | Composition |
|---|---|
| Carbon (C) | max 0.21 % |
| Manganese (Mn) | 0.90–1.35 % |
| Phosphorus (P) | max 0.035 % |
| Sulfur (S) | max 0.035 % |
| Silicon (Si) | 0.10–0.40 % |
Distinct ranges for Grades I and II depending on wall thickness:
| Grade | Wall Thickness | Yield Strength (min) | Tensile Strength | Elongation (2″ gauge) |
|---|---|---|---|---|
| I | ≤ 0.375″ (9.52 mm) | 35 000 psi (~240 MPa) | 60 000–85 000 psi (414–586 MPa) | ≥ 30 % |
| II | > 0.375″ (9.52 mm) | 30 000 psi (~205 MPa) | 55 000–80 000 psi (380–550 MPa) | ≥ 25 % |
These pipes also undergo flattening, hydrostatic, bending, and tensile tests as part of quality assurance A
While this spec encompasses two grades, only Grades I and II are standardized for A524. Alternative low-temperature pipes—such as ASTM A333—exist but are distinct standards (not within A524 itself)
ASTM A524 (A524/A524M-21) is the primary reference standard
Designation includes both inch-pound and SI units but prioritizes inch-pound unless "M" is specified
A524 pipes are well-suited for:
Hydraulic and pneumatic systems
Oil and gas industry pipelines
Pressure vessels, heat exchangers
Automotive components and structural use
Chemical processing, marine, power generation, water supply
In oil & gas, for low-temperature fluid transport or cold climates
In petrochemical plants, as conduit for volatile chemicals
In power plants, as piping for cold feedwater or low-temperature steam
In automotive, for hydraulic cylinder tubing or precision hydraulic lines
In chemical processing, for corrosion-prone or low-temp pipelines
| Category | Specification Summary |
|---|---|
| Material | Killed low-carbon steel |
| Grades | I (thin) and II (thick) |
| Chemistry | C ≤ 0.21%, Mn 0.90–1.35%, P/S ≤ 0.035%, Si 0.10–0.40% |
| Mechanical | Grade I: YS ≥ 240 MPa, TS 414–586 MPa, Elong ≥ 30%; Grade II: YS ≥ 205 MPa, TS 380–550 MPa, Elong ≥ 25% |
| Testing | Flattening, hydrostatic, tensile, bend tests |
| Manufacture | Hot-finished or cold-drawn |
| Applications | Hydraulic, oil & gas, automotive, chemical, power, structural, marine |
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock,
it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
|
