High-Pressure Variable Displacement Piston Pump
A10VSO71DFLR/31R-PPA12N00 Series
High-performance hydraulic pump motor designed for demanding
industrial appliions, featuring variable displacement technology
with a maximum pressure rating of 350 bar.
Product Specifiions
| Attribute | Value |
|---|
| Model | A10VSO |
| Control Type | Variable Displacement |
| Maximum Pressure | 315 bar |
| Seal Type | Lip Seal Or Mechanical Seal |
| Shaft Seal Type | Radial Shaft Seal |
| Usage | Oil |
| Certifiion | ISO9001 |
| After Service | Online video support |
Key Features
- High pressure operation up to 350 bar
- Low noise design for improved working environment
- Reliable quality with durable construction
- Variable displacement for precise flow control
- Energy efficient operation
Technical Details
Power Source: Electric (1.5-7.5KW)
Structure: Piston pump
Delivery Time: Within 5 days after receiving payment
Appliions
Injection molding machines, cutting machines, plastic machinery,
leather processing equipment, blowing machines, forging and
engineering machinery.

Available Models in A10VSO Series
A10VSO18, A10VSO28, A10VSO45, A10VSO71, A10VSO100, A10VSO140
Frequently Asked Questions
What is the A10VSO71 series?
The A10VSO71 is a variable displacement axial piston pump with
swashplate design, designed for hydrostatic transmission in open
circuits. It offers stepless flow regulation by adjusting the
swashplate angle and is widely used in high-power hydraulic systems
for industrial and mobile appliions.
What are the key features of the A10VSO71 pump?
- Pressure Range: Nominal pressure of 280 bar, peak pressure of 350 bar
- Flow Control: Proportional to drive speed and displacement, adjustable via
swashplate angle
- Efficiency: Energy saving modes reduce consumption by 30% compared to fixed
pumps
- Durability: Fluorocarbon (FKM) shaft seals and fluid hydrostatic bearing
technology
What control options are available?
The series offers multiple control modes including pressure control
(DR/DRG), pressure and flow composite control (DFR), integrated
control of pressure, flow and power (DFLR), and electrohydraulic
proportional control (ED/EP).
How to install the pump correctly?
- Prefer horizontal shaft mounting
- Shell drain ports must be separately led to the fuel tank
- Maintain ≥ 0.8 bar absolute pressure at the inlet
- Use SAE standard flange ports and vibration-resistant connectors
