Serrated Steel Grating Bearing Bar Spacing 1– 1/4" X 1/4" China Stainless Steel Trench Grate Wholesalers

Product Introduction

THE POPULAR SPECIFICATIONS OF STEEL GRATING

The grating with a pitch of 30mm between bearing bars is the most widely used type in the industrial field. Among normal types, it has the strongest resistance to surface lash.

The grating with a pitch of 40mm between bearing bars is the most economical and lightest type. lt is the best choice for you on occasions when the span is small.

The grating with a pitch of 60mm between the bearing bars and a pitch of 50mm between the cross bars is developed especially for the mining industry, it solved the problem of a mineral splash on the plate. So it is often appointed for use in processing works of the mining industry.

The grating with a pitch of 30mm between bearing bars and of76mm between cross bars is the most popular type used at home and abroad, it is proper for many applications such as walkways, platforms, etc.

STAINLESS STEEL GRATING - 304 & 316 MATERIALS FOR CORROSIVE PROJECTS

Stainless steel grating is regarded as industrial-grade bar grating, which is extremely strong, durable, and corrosive resistant for all load-bearing applications and is primarily used for pedestrian and light vehicle traffic.

- Both in Smooth or serrated surface.
- 304 or 316 grade for choice.
- Wide range of bearing bar sizes and pitches.
- Special discount for large orders.
- Project references can be supplied for your bid.
- ISO Certificated factory.
- CAD or 3D drawings can be supplied for your design and construction.

Applications

It can provide durable grating solutions for corrosive resistance and minimum carbide precipitation are important considerations, typical applications include stairs and platforms for chemical production and storage, food processing, and water and wastewater treatment plant.

Dimensions

• Material: stainless steel 304, 304L, 316, 316L.
• Finish: mill finish, commercial clean, and electro-polished.
• Bearing bar spacing: ranging from 1-3/16" to 11/16".
• Cross bar spacing: 2" or 4" on center.

GNEE STEEL ,Has dedicated in producing and exporting all types of steel gratings for more than 19 years,A Professional Steel Grating & Safety Grating Manufacturer for Projects Engineering.

Factory

Advanced Equipment

We have more than 30 production lines of welded steel gratings and press lock gratings. Advanced equipment, skilled workers contribute to low production loss, high production efficiency and low products costs.

Supervise Strict Testing

All steel gratings are supervised by strict QUALITY CONTROL System both in International standard and enterprise test flow. All products our customers received are qualified and best in performance and package.

Steel Gratings Types We Supply

GNEE Steel Grating Application

Steel grating are designed and manufactured for various industrial and civil constructions in city road, gardens, yard, airport, railway and industrial engineering.

• Hot dip galvanized steel grating is the best choice for steel platforms in airports. Grating with 30 × 3 mm thick load bearing bars with a pitch of 30 mm and traverse bars at 50 mm or 100 mm is the suitable one.
• Steel grating, with robust design and spanning abilities, is very strong and safe for the support of floors and elevated walkway. It can be used for ceiling, interior decoration, platform aisle, ventilation windows, (Wells), advertising plaque and other construction.
• Widely used in the petrochemical industry, power plants, waterworks, sewage treatment plants, municipal works, sanitation projects in areas such as platforms, corridors, bridge, ditch cover, covers, ladders, fences, rails, and so on.
