LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon

LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon

LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon
LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon
Categories Waterproof Circular Connector
Brand Name: Cablein
Certification: CE, ROHS, TUV , ETL
Place of Origin: Shenzhen China
MOQ: 100PCS
Price: The price ranges from $1 to $4 USD per pieces
Payment Terms: T/T,Western Union
Delivery Time: 5-8 Working Days
Packaging Details: High Quality export carton
Assembly Wire: Soldering Or Screw Fitting
Operating Temperature: -40°C to +85°C
Interface Type: AC/DC
Contacts Number: 2-12 pins
Connector Type: Waterproof Connector
Voltage Rating: 250V
Protection Level: IP67
Connection: terminal box/compensation cable/head
Contact Now
Company Info.
Cablein Technology Co., Ltd.
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

LP20 5 Pin IP67 Waterproof Connector 10A Flange Mount Metal-Nylon

LP20 Series 5 Pin 10A Flange Mount Solderable Waterproof Connector - Metal & Nylon Composite
Specifications
  • Pin: 5 Pin
  • Current Rating(A): 10A Max
  • Material: Metal+plastic
  • Conenction Way: Push-button snap fastener
  • Operating Voltage: 500V Max
  • Assembly Wire: IP-Rated Locking Gland
  • Mounting Type: Flange Mounting Type
  • Out Door UV Resistance: Pass
  • Cable Jacket OD: 1-1.5 mm²
LP20 Series 5 Pin 10A Flange Mount Solderable Waterproof Connector - Metal & Nylon Composite datasheet
Pins Number2Pins3Pins4Pins5Pins7Pins9Pins12Pins
Rated Voltage500V
250V
Rated Current20A10A5A
Insulation voltage2.5KV1.5KV
IP CODEIP68
Cable Jacket ODStandard Power:⌀8-12mm Standard Signal :⌀5-6.5mm Other:⌀5-9mm
Assembly cable diameter2.4-4mm²/14-12AWG1-1.5mm²/18-16AWG0.34-0.75mm²/22-20AWG
Ambient temperature-40℃~+80℃
LP20 Series 5 Pin 10A Flange Mount Solderable Waterproof Connector - Metal & Nylon Composite Advantages:
  1. Material & Performance:
    The housing is made of high-performance PBT engineering plastic, ensuring stable electrical properties, excellent heat resistance, and corrosion resistance. The gold-plated conductive components guarantee superior conductivity and meet temperature rise requirements even in high-temperature environments.
  2. Secure Locking Mechanism:
    Features a push-to-lock snap-fit design for secure mating and smooth insertion/removal.
  3. Waterproof Design:
    Standard IP67 rating (IP68 optional) provides precise waterproof protection.
  4. Certifications & Compliance:
    Complies with TUV, ISO, CE, and RoHS certifications, meeting global market requirements.
LP20 Series Connector LP20 Series Connector Close-up LP20 Series Connector Side View
LP20 Series 5 Pin 10A Flange Mount Solderable Waterproof Connector - Metal & Nylon Composite Application industries
  • Automation Equipment
  • LED Lighting
  • Security Equipment
  • Telecommunication Equipment
  • New Energy
  • Electronic Devies
LP20 Connector in Application
LP20 5-Pin Waterproof Electrical Connector 10A IP67 Metal-Plastic Flange Type Drawing
LP20 Connector Technical Drawing LP20 Connector Technical Drawing
FAQ
Q: What makes this connector truly waterproof, and what is its IP rating?
A:This LP20 connector is engineered for superior sealing performance. It achieves an IP68 rating when properly mated, which is the highest level of ingress protection commonly certified for connectors. This means it is completely dust-tight (6) and can withstand continuous submersion in water beyond 1 meter depth (8), making it ideal for harsh outdoor, marine, or industrial environments. The waterproofing is achieved through precision-mated silicone seals within the connector body and a robust interface seal between the plug and socket.
Q: Why is the housing made from a Metal and Nylon composite, and what are the benefits?
A:The hybrid metal and nylon composite construction offers the best of both worlds. The metal parts (typically the flange and shell) provide exceptional EMI shielding protection, structural rigidity, and resistance to crushing impacts. The nylon components offer high corrosion resistance, excellent dielectric insulation, and are lightweight, which reduces overall weight and prevents galvanic corrosion. This combination results in a connector that is far more durable and reliable in demanding applications than all-plastic versions, while offering significant advantages over heavier all-metal designs.
