| Categories | DC Worm Gear Motor |
|---|---|
| Model Number: | FT-12SGMN20 |
| Brand Name: | FUTENG |
| Place of Origin: | China |
| MOQ: | 1000 Pieces |
| Price: | Negotiable |
| Certification: | CE/ROHS/FCC/REACH/ISO14001/ ISO9001/ISO45001/IATF16949 |
| Packaging Details: | Standard Export Carton & Customzied |
| Delivery Time: | 15-30 days/Negotiable |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability: | 8000 0000 |
| Efficiency: | 48%-81% |
| Speed(RPM): | 5rpm-450rpm |
| Commutation: | Brush |
| Construction: | Permanent Magnet |
| Rated Power: | 1-48w |
| Rated voltage: | 3-24v |
| Usage: | Boat, Car, Electric Bicycle, Fan, Home Appliance, Cosmetic Instrument, Smart Home |
| Warranty: | 3 months ~ 1 year |
| Geared motor model: | FT-12SGMN20 |
| Gearbox parameters: | RH MOTOR |
| Reduction ratio: | 59,118,236(K) |
| Gearbox diameter: | 1 2mm worm gear |
| Gear box length L: | 18(mm) |
| Dimensions: | 10*12*18 |
| Name: | DC Worm Gear Motor |
| Company Info. |
| Dongguan Futeng Motor Co., Ltd |
| Verified Supplier |
| View Contact Details |
| Product List |
Gearbox Data | RH MOTOR | ||||
Gear stages | 4 | Geared motor model | RH-12SGMN20 | ||
Reduction ratio (K) | 59,118,236 | Gearbox diameter | 12mm worm gear | ||
Gear box length L(mm) | 18 | Voltage | 3-24V | ||
Gearbox efficiency (%) | 30% | Rotating speed | 5rpm- 450rpm | ||
Reducer performance parameters: | ||||||
Serial number | Reduction ratio | Dimensions | Rated torque | Momentary allowable torque | noise | |
1 | 59 | 10*12*18 | 100g.cm | 300g.cm | <50db | |
2 | 118 | 10*12*18 | 230g.cm | 700g.cm | <50db | |
3 | 236 | 10*12*18 | 450g.cm | 1350g.cm | <50db | |
|
