| Categories | Light Testing Equipment |
|---|---|
| Brand Name: | HongCe |
| Model Number: | HDJ0008 |
| Certification: | calibration certificate (cost additional) |
| Place of Origin: | China |
| MOQ: | 1 set |
| Price: | Negotiatable |
| Payment Terms: | T/T,L/C |
| Supply Ability: | 10 set /month |
| Delivery Time: | 30 days |
| Packaging Details: | plywood |
| Warranty: | 1 Year |
| Product name: | Lighting Adjustment Device Tester |
| Model: | HDJ0008 |
| Action angle of rotation: | 0-360° |
| Controller: | Mitsubishi PLC |
| HMI: | touch screen interface |
| Language: | English |
| Load: | Optional |
| Company Info. |
| Guangzhou HongCe Equipment Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Adjustable Light Fitting Positioning & Angle Alignment Device for Precision Lamp Testing | Professional Light Testing Equipment for LED, Luminaires & Optical Performance Evaluation
The HDJ0008 Adjustable Light Fitting Device is designed to simplify and standardize lamp positioning during optical and performance testing. Built by HongCe, a trusted original manufacturer in China, this device ensures consistent angle alignment, stable mounting, and precise positioning for a wide range of lighting products—from LED bulbs to indoor and industrial luminaires. It is an essential component for professional Light Testing Equipment setups.
| Item | Parameters |
| test rate | 0.1 to 10 times / min, can be set |
| bending angle | 0-180° |
| Rotation center height | 1200mm |
| The maximum radius of gyration of the pendulum | R500mm |
| Maximum stroke of stretching action | 0-650mm |
| Action angle of rotation | 0-360° |
| Test cycles | 1-999999, can be set |
| Drive motor | Servo motor |
| HMI | touch screen interface |
| Load | with terminals, Externally connected to load(The load is optional,cost additional ). |




|
