2000kva Substation Power Transformer ONAF Step Down 34.5kv To 480v Electrical Substation Transformer

2000kva Substation Power Transformer ONAF Step Down 34.5kv To 480v Electrical Substation Transformer

Summarization

A substation is a critical node in an electrical grid that facilitates the transmission and distribution of electricity. Substations are equipped with essential components such as transformers, circuit breakers, switches, and monitoring systems. Their primary purpose is to adjust voltage levels, route power flow, and ensure system stability and safety.

Product Photos

WINLEY Electric's substation transformers are designed to meet ANSI/IEEE and IEC standards, with capacities ranging from 150KVA to 63MVA and voltage ranges typically from 2.4KV to 69KV. They feature low partial discharge, low loss, low noise, light weight, and long service life.

Main Data

Technical drawings

Standard Specifications

• LBOR Switch
• External Lockable Gauges, Bayonet Fuses, and Switch
• Liquid Temperature Gauge (Dial-type Thermometer)
• External Lockable Drain & Sample Valve
• Liquid Level Gauge
• Pressure Vacuum Gauge
• Pressure Relief Valve
• DOE 2016 Efficiency
• All Stainless Steel Hardware

Optional Specifications

• Gauges with Alarm Contacts
• Fan Package
• Bi-Directional (Step-Up) Rated with Electrostatic Shield
• Throated Connection for Close-Coupling
• External Drain and Sample Valve in Lockable Box
• Skid-Mounted Options
• K-Factor up to K-13
• Extended Cabinet Depth to allow for T-OP connectors
• Dual Voltage
• FR3
• Inert Gas Oil Preservation System (High Voltage)
• Fan Package (High Voltage)
