785B 785C 785D Hydraulic pump for Excavator spare parts 232-1835 Axial Piston pump

785B 785C 785D Hydraulic pump for Excavator spare parts 232-1835 Axial Piston pump

Application	Excavator
Part Name	Hydraulic Main Pump
Model	785B 785C 785D
Part Number	232-1835
Warranty	6-12 months
Payment Term	T/T, Trade Assurance, Paypal and etc.
Brand	belparts

List of spare parts

#	Part No	Part Name	Qty.
1	1U0323	PLUG ASSEM.	3
		(EACH INCLUDES)
1A	1U0322	BEARING-SLEEVE (12.65MM ID)	1
2	3P9498	PLUG-ORIFICE	1
4	6E5066	SCREEN (CONTROL VALVE MANIFOLD)	1
5	6J3380	SPRING	1
6	7J7423	VALVE (SECONDARY STEERING PUMP CHECK)	3
7	8B4624	SHIM .81MM(.032IN)THK .82MM(.032IN.)THK.	7
7A	8B4624	SHIM .81MM(.032IN)THK .82MM(.032IN.)THK.	5
8	8J2379	VALVE-RELIEF (BRAKE COOLING)	1
9	1067683	ADAPTER	1
10	1138263	PISTON	1
11	1185081	ACTUATOR GROUP-PILOT CONTROL -AUXILIARY DUAL STAGE, HOIST	2
12	1266612	BODY	1
14	1322049	BODY	1
15	1322051	VALVE GROUP-RELIEF -AUXILIARY DUAL STAGE, HOIST	1
17	1327102	VALVE GROUP-COUNTERBALANCE (HOIST/AUXILIARY)	1
19	1621492	CONNECTOR	1
20	0304606	SEAL (use as required)	1
21	1266104	PLUG	1
22	1488407	PLUG (HEX HEAD) (-6 ORB) (CURRENT) (1616435 FRICTION DISC INTERCHANGEABLE WITH 1186547) (USE ALL OF ONE PART NUMBER)	6
		(EACH INCLUDES)
	3J1907	SEAL VALVE ASSEMBLY TO SEAL- TUBE ASSEMBLY TO LOGIC VALVE	1
	9S4191	PLUG,MACHINE THREAD FUEL INJECTION PUMP	1
23	1488409	PLUG AS-STO	1
	3D2824	O-RING - FOR OIL DRAIN & LEVEL PLUG (ITEMS 3 & 7)	1
	9S8008	PLUG-O-RING (COOLANT TEMPERATURE REGULATOR)	1
24	1488411	PLUG GROUP	2
		(EACH INCLUDES)
	3K0360	SEAL PILOT MANIFOLD ON SEAL TO BOOM CHECK VALVE DRAIN	1
	9S4185	PLUG--TO SEAL HYDRAULIC PUMP TO SUMP OF LIMIT SYSTEM	1
25	1620177	PLUG AS	1
	3J1907	SEAL VALVE ASSEMBLY TO SEAL- TUBE ASSEMBLY TO LOGIC VALVE	1
	9S8004	PLUG-O-RING (STRAIGHT THREAD O-RING)	1
26	1733993	PLUG AS	2
		(EACH INCLUDES)
	4J7533	SEAL FUEL INJECTION PUMP	1
	9S8001	PLUG-O-RING (5/16-24 THD)	1
27	1837263	PLUG GROUP	1
	3J7354	PACKING,PREFORMED PART OF KIT P/N 5R1427	1
	9S8002	PLUG-O-RING (STRAIGHT THREAD O-RING)	1
28	1P3709	SEAL-RECTANGULAR	1
29	1P4578	FLANGE (TO 5V6409 TUBE ASSEMBLY)	8
30	1P4579	FLANGE (HALF)	4
31	1P4582	FLANGE-HALF	2
32	1P4584	FLANGE-HALF	4
33	2S4078	SEAL-O-RING (ID=37.47mm)	3
34	3D4603	PLUG-PIPE (1/16-27 NPTF THD)	2
35	3K6113	WASHER-HARD (.118MM THK)	4
36	4H5232	PIN (Spring)	3
37	4J0522	SEAL-INTERFACE BETWEEN 3RD & TILT VALVE	1
38	4J0523	PACKING,PREFORMED COVER AND VALVE BODY	1
39	4J0527	SEAL-O-RING -PIPE AS. TO HYDRAULIC TANK	1
40	5H6005	SEAL-O-RING (10.77MM ID)(SMALL)	1
41	5P2566	CAPSCREW (HEX HD) (1/2-13 NC X 1 1/2) (GD 8 Z)	12
42	5P6300	SEAL-O-RING	1
43	6K6307	SEAL-O-RING (43.69MM ID)	1
44	6V4432	CAPSCREW, HEX HEAD (1/2 NC X 4)	4
45	6V7418	PLUG-PIPE	2
46	6V8676	SEAL-O-RING (48.90MM ID)	1
47	7B7525	BOLT-SOCKET HEAD (7/16-14X1.25-IN)	4
48	7S8491	SPRING	3
49	7X0293	BOLT-FOR TRANSMISSION FILTER RETURN LINE	2
50	7X0301	BOLT-PLT (3/8UNC X 7)	2
51	7X0335	BOLT-PLT (1/2UNC X 5 1/4)	5
52	7X0584	WASHER-HARD (13.5X20.5X2-MM THK)	7
53	8T4223	WASHER-HARD (13.5X25.5X3-MM THK)(BOLT TO SHIELD)	24
54	8T5360	WASHER-HARD (FOR USE WITH 7/16 IN BOLTS)	16
55	8T8916	BOLT-PLT (7/16UNC X 1 1/2)	16
56	8T8919	CAPSCREW (1/2-13X1 3/4" GD8)	8
57	8T8920	B. 1/2 n.c. x 3 1/4"	4
58	9P8217	WASHER (10X14.68X1.65-MM THK)	4

		AVAILABLE REPAIR KIT(S):
	6E5283	KIT-SEAL (COUNTERBALANCE VALVE)(HOIST)	1
		(INCLUDES RINGS & SEALS)
		USE AS REQUIRED
		KIT MARKED J AVAILABLE FOR PART MARKED J
		SEPARATE ILLUSTRATION

Detailed components of hydraulic main pump
