| Categories | PP Strap Production Line |
|---|---|
| Brand Name: | HL |
| Model Number: | HL-PP |
| Certification: | CE |
| Place of Origin: | CHINA |
| MOQ: | 1set |
| Price: | usd 10000.00-56000 |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 10-20 set/Monthly |
| Delivery Time: | 20-30days |
| Packaging Details: | PE film |
| Name: | PP strapping production line |
| Material: | 100% PP new material |
| Strap Width: | 5-19 mm |
| Strap Thickness: | 0.3-1.2 mm |
| Paper core diameter: | 200*180 mm |
| Screw: | 110*3300 mm |
| Screw Material: | 38CrMoALA |
| Line speed: | 100-300 m/min |
| Extrusion type: | single/twin screw |
| Production capacity: | 100-600 KG/ H |
| Embossing wheel: | one/two |
| Embossing wheel material: | skd-11 |
| Company Info. |
| Hainan Huili Packaging Products Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
PP strapping production line 5-19 mm Single / twin screw PP strapping production equipment
DESCRIPTION OF PP STRAPPING PRODUCTION LINE:
PP strapping production line
Features
1. The winding machine uses imported accessories, torque motor control, flattened winding, small deviation on both sides, suitable for use with fully automatic strapping machines.
2. The winding machine can wind 5-19mm PP strapping tape for packaging, and can be wound by meter or weight.
3. The multifunctional winding machine has good flexibility, and the height and diameter of the paper core can be customized according to customer requirements.
EXTRUSION PARAMETERS TABLE
| Model | PP-2 | PP-4 | PP-6 | PP-8 | PP-10 | PP-12 |
| Raw material | PP polypropylene new material/recycled material | |||||
| Number of tapes | 2 | 4 | 6 | 8 | 10 | 12 |
| Width(mm) | 5-19 | 5-19 | 5-19 | 5-19 | 5-19 | 5-19 |
| Thickness(mm) | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 | 0.4-1.2 |
| Line speed(m/min) | ≧260-300 | |||||
| PLC control system | PLC | PLC | PLC | PLC | PLC | PLC |
| Screw Model | 90 | 110 | 125 | 135 | 135 | 135 |
| Reducer model | 200 | 220 | 250 | 280 | 280 | 280 |
| Winding machine | Automatic winding machine /Semi-automatic winding machine | |||||
| Screen Changer | Automatic/Manua | |||||
| Production capacity 24H | 2.5-3T | 6-7T | 8-9T | 10-11T | 12-13T | 13--14T |

Advantages of PP strapping production line:
1. This production line is specially designed for PP strapping production, and can produce 2-12 PP strapping strips at the same time, saving energy by 30%-40%;
2. The shaping water tank is made of stainless steel and is durable;
3. It adopts PLC touch screen control, supports multi-language switching, safe and convenient operation, and keeps all components in good condition, ensuring stable performance of the whole line and continuous production of PP strapping strips.
Function:
1) PP raw materials do not need to be dried and water treated separately, and the preheating and drying processes are automatically circulated, saving a lot of equipment investment and reducing production costs by 30%;
2) Recycled bottle flakes are used as raw materials to greatly reduce costs;
3) Low energy consumption and high production capacity;
4) Easy operation, saving manpower, an average of two people can be saved for one production line

PP strapping belt is suitable for strapping machines:
Fully automatic strapping machine
Semi-automatic strapping machine
High-speed strapping machine
Handheld electric strapping machine
Manual strapping machine (iron buckle)

ABOUT AFTER-SALES
We provide comprehensive technical support and service for our PP Strap Making Machine. Our team of experienced technicians can provide a variety of services, including:
Pre-sales:
1.Layout plan of PP strapping production line.
2.Analysis of the cost of PP strapping production line.
3.Raw materials that can be used for PP strapping production line.
After-sales service:
1.Water and electricity circuits of PP strapping production line. circuit drawings, etc.
2.Installation, commissioning and training of PP strapping production line.
3.Maintenance service of PP strapping production line.
4.Regular maintenance and repair
5.Troubleshooting and diagnosis
6.Software updates and upgrades
7.Spare parts and accessories
8.Training and technical advice
FAQ:
Q:What is the voltage of PP strapping production line?
A:380V/50HZ, we support customization
Q:Can the PP strapping production line be customized according to the factory length?
A:Yes, we can customize the length according to the customer's
factory size.
Q:Where is the PP strapping production line?
A:We are from China.
Q:Can PP strapping production line provide after-sales service?
A:Yes, we have professional after-sales engineers who provide
24-hour online guidance.
Q:Is the quality of PP strapping production line stable?
A:We have 30 years of manufacturing experience, and have their own PP strapping production line plant, equipment quality is stable, the process is worth choosing.
Q:Does PP strapping production line support customization?
A:We are a manufacturing plant that can customize model size,
extrusion capacity, voltage and so on according to customer
requirements.
|
