White Aluminium Strip False Ceiling Aluminum Baffle Panel Wit Pvdf Coating Acp Sheets

Categories PE Aluminum Composite Panel
Brand Name: Alushang
Model Number: 1220*2440MM 4MM
Certification: ISO
Place of Origin: China
MOQ: 300meter square
Price: negotiable
Payment Terms: T/T,L/C,D/A,D/P
Supply Ability: 30000 Meter square /day
Delivery Time: 15-20days
Packaging Details: wooden package
Coating: Fluorocarbon (PVDF)
Origin: China
Core Types: AA (Unbreakable Core) And AB (normal Core)
Applications: Aluminum Solar Panel Installation, Architectural Cladding, Interior Design, Furniture Design
Core Materiabls: unbreakable core
Weight: 3.8-4.5kg/sqm
Thickness: 3mm, 4mm, 5mm
Material: Aluminum, PE core
Tensile Strength: ≥130Mpa
Causality: Factory
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

White Aluminium Strip False Ceiling Aluminum Baffle Panel Wit Pvdf Coating Acp Sheets

Pe with PVDF Aluminum Composite Panels are an ideal choice for pursuing a building exterior that "stands the test of time." They address the issue of rapid aging and color loss common in traditional materials exposed to outdoor environments.

It is a three-layer composite panel with a core structure consisting of two aluminum sheets bonded to a plastic core (typically PE). Its key differentiating feature is the PVDF fluorocarbon coating applied to the exterior surface.

Structural Breakdown



LayerMaterialFunction & Notes
Top CoatClear PVDF VarnishFinal protective layer, provides gloss and self-cleaning effect.
Primer/Color LayerPVDF Resin (≥70%) + PigmentsCore functional layer, provides color and primary weatherability.
Chemical PretreatmentChromate or Chromate-free Conversion CoatingEnhances coating adhesion to aluminum and provides anti-corrosion.
Top SkinAluminum Alloy (e.g., AA3003)Structural layer, typically 0.2-0.5mm thick.
Core LayerPolyethylene (PE) or Fireproof CoreCritical differentiator. PE core is economical but flammable. For fire safety requirements, a fireproof core (e.g., mineral wool/inorganic filler) must be selected.
Bottom SkinAluminum AlloyBacking structural layer, usually coated with a protective polyester paint.

Primary Application Areas

  • High-end building curtain walls and exterior wall cladding (commercial towers, shopping malls, airports, stadiums)

  • Large-scale outdoor signage and billboards

  • Exterior renovation of old buildings

  • Interior decoration requiring long-term color and appearance consistency

Packing and Shipping:

Product Packaging and Shipping:

The PE Aluminum Composite Panel is carefully packaged to ensure its safe delivery to you. Each panel is wrapped in protective film and then packed in sturdy cartons to prevent any damage during transit.

For shipping, we partner with reliable carriers to deliver your order securely and on time. You can track your package using the provided tracking number for peace of mind.


FAQ:

Q: What is the brand name of the PE Aluminum Composite Panel?
A: The brand name is Alushang.

Q: What is the model number of the PE Aluminum Composite Panel?
A: The model number is 1220*2440MM 4MM.

Q: What certifications does the PE Aluminum Composite Panel have?
A: The panel is certified by SGS and ISO.

Q: Where is the PE Aluminum Composite Panel manufactured?
A: The panel is manufactured in China.

Q: What is the minimum order quantity for the PE Aluminum Composite Panel?
A: The minimum order quantity is 300 square meters
