| Categories | Fire Resistant Cable |
|---|---|
| Brand Name: | Zhongdong |
| Model Number: | NYY NYBY |
| Certification: | IEC,CE,ISO,TUV |
| Place of Origin: | Hebei，China |
| MOQ: | Negotiable |
| Price: | Negotiable |
| Payment Terms: | ,L/C,T/T |
| Supply Ability: | 100KM/Week |
| Delivery Time: | 7-30 days based on different qty |
| Packaging Details: | Rolls, Wooden Drums, Steel Drums, Reels or customized |
| Voltage: | 450/750V |
| Insulation: | XLPE |
| Jacket: | PVC |
| Feature: | PVC |
| No of Cores: | 1-61 CORES |
| Standards: | VDE 0276 part 604, VDE 0482-266-2, DIN EN 60332-3 / EN50266-2 |
| Company Info. |
| Zhongdong Cable Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
This product is suitable for use in control, monitoring circuits, and protection circuits in circuits with a rated voltage of 450/750V and below
Conductor
Circular solid copper conductor(A) or circular stranded copper conductor(B)
Insulation
Polyvinyl chloride (PVC)
Filler
Polypropylene(PP) mesh filling rope
Armouring (optional)
Galvanized steel tape
Outer sheath
Polyvinyl chloride (PVC)
| Spec mm² | Conductor No core/mm | Conductor diameter mm | Approximate outer diameter of cable mm | Approximate cable weight kg/km | ||||||
| None-flame | ZA | ZB | ZC | None-Flame | ZA | ZB | ZC | |||
| 2×0.75 | 1/1.02 | 1.02 | 7.2 | 7.3 | 7.3 | 7.2 | 57.9 | 61.6 | 61.6 | 57.9 |
| 2×1 | 1/1.13 | 1.13 | 7.5 | 7.6 | 7.6 | 7.5 | 65.1 | 69.0 | 69.0 | 65.1 |
| 2×1.5 | 1/1.38 | 1.38 | 8.4 | 8.5 | 8.5 | 8.4 | 84.4 | 89.2 | 89.2 | 84.4 |
| 2×2.5 | 1/1.76 | 1.76 | 9.6 | 9.7 | 9.7 | 9.6 | 116.2 | 122.1 | 122.1 | 116.2 |
| 2×4 | 1/2.22 | 2.22 | 10.6 | 10.7 | 10.7 | 10.6 | 153.7 | 160.6 | 160.6 | 153.7 |
| 2×6 | 1/2.74 | 2.74 | 11.7 | 11.8 | 11.8 | 11.7 | 201.9 | 210.1 | 210.1 | 201.9 |
| 2×10 | 7/1.35 | 4.0 | 15.8 | 16.3 | 16.3 | 15.8 | 341.3 | 364.3 | 364.3 | 341.3 |
| 3×0.5 | 1/0.85 | 0.85 | 7.2 | 7.3 | 7.3 | 7.2 | 58.2 | 63.6 | 63.6 | 58.2 |
| 3×0.75 | 1/1.02 | 1.02 | 7.5 | 7.7 | 7.7 | 7.5 | 68.4 | 74.4 | 74.4 | 68.4 |
| 3×1 | 1/1.13 | 1.13 | 7.9 | 8.0 | 8.0 | 7.9 | 80.8 | 84.6 | 84.6 | 80.8 |
| 3×1.5 | 1/1.38 | 1.38 | 8.9 | 9.0 | 9.0 | 8.9 | 106.8 | 111.4 | 111.4 | 106.8 |
| 3×2.5 | 1/1.76 | 1.76 | 10.2 | 10.3 | 10.3 | 10.2 | 150.5 | 156.1 | 156.1 | 150.5 |
| 3×4 | 1/2.22 | 2.22 | 11.2 | 11.4 | 11.4 | 11.2 | 203.3 | 209.9 | 209.9 | 203.3 |
| 3×6 | 1/2.74 | 2.74 | 12.4 | 12.5 | 12.5 | 12.4 | 271.6 | 279.3 | 279.3 | 271.6 |
| 3×10 | 7/1.35 | 4.0 | 16.8 | 17.3 | 17.3 | 16.8 | 457.6 | 480.2 | 480.2 | 457.6 |
| 4×0.5 | 1/0.85 | 0.85 | 7.7 | 7.9 | 7.9 | 7.7 | 69.9 | 75.9 | 75.9 | 69.9 |
| 4×0.75 | 1/1.02 | 1.02 | 8.2 | 8.3 | 8.3 | 8.2 | 83.1 | 89.8 | 89.8 | 83.1 |
| 4×1 | 1/1.13 | 1.13 | 8.5 | 8.7 | 8.7 | 8.5 | 95.6 | 102.8 | 102.8 | 95.6 |
| 4×1.5 | 1/1.38 | 1.38 | 9.7 | 9.8 | 9.8 | 9.7 | 127.7 | 137.0 | 137.0 | 127.7 |
| 4×2.5 | 1/1.76 | 1.76 | 11.1 | 11.3 | 11.3 | 11.1 | 188.3 | 194.5 | 194.5 | 188.3 |
| 4×4 | 1/2.22 | 2.22 | 12.3 | 12.4 | 12.4 | 12.3 | 257.3 | 264.6 | 264.6 | 257.3 |
| 4×6 | 1/2.74 | 2.74 | 14.2 | 14.3 | 14.3 | 14.2 | 364.5 | 373.9 | 373.9 | 364.5 |
| 4×10 | 7/1.35 | 4.0 | 18.4 | 19.0 | 19.0 | 18.4 | 583.4 | 608.3 | 608.3 | 583.4 |
| 5×0.5 | 1/0.85 | 0.85 | 8.4 | 8.5 | 8.5 | 8.4 | 84.7 | 88.8 | 88.8 | 84.7 |
| 5×0.75 | 1/1.02 | 1.02 | 8.9 | 9.0 | 9.0 | 8.9 | 101.4 | 105.8 | 105.8 | 101.4 |
| 5×1 | 1/1.13 | 1.13 | 9.2 | 9.4 | 9.4 | 9.2 | 117.1 | 121.8 | 121.8 | 117.1 |
| 5×1.5 | 1/1.38 | 1.38 | 10.5 | 10.7 | 10.7 | 10.5 | 157.9 | 163.6 | 163.6 | 157.9 |
| 5×2.5 | 1/1.76 | 1.76 | 12.1 | 12.3 | 12.3 | 12.1 | 227.4 | 234.5 | 234.5 | 227.4 |
| 5×4 | 1/2.22 | 2.22 | 14.0 | 14.1 | 14.1 | 14.0 | 330.5 | 339.6 | 339.6 | 330.5 |
| 5×6 | 1/2.74 | 2.74 | 15.5 | 15.6 | 15.6 | 15.5 | 442.8 | 453.5 | 453.5 | 442.8 |
| 5×10 | 7/1.35 | 4.0 | 20.2 | 20.8 | 20.8 | 20.2 | 712.7 | 740.8 | 740.8 | 712.7 |
| 6×0.5 | 1/0.85 | 0.85 | 9.0 | 9.2 | 9.2 | 9.0 | 97.7 | 102.3 | 102.3 | 97.7 |
| 6×0.75 | 1/1.02 | 1.02 | 9.6 | 9.7 | 9.7 | 9.6 | 117.6 | 122.6 | 122.6 | 117.6 |
| 6×1 | 1/1.13 | 1.13 | 10.0 | 10.1 | 10.1 | 10.0 | 136.4 | 141.7 | 141.7 | 136.4 |
| 6×1.5 | 1/1.38 | 1.38 | 11.4 | 11.6 | 11.6 | 11.4 | 184.9 | 191.5 | 191.5 | 184.9 |
| 6×2.5 | 1/1.76 | 1.76 | 13.8 | 13.9 | 13.9 | 13.8 | 285.2 | 294.4 | 294.4 | 285.2 |
| 6×4 | 1/2.22 | 2.22 | 15.2 | 15.4 | 15.4 | 15.2 | 389.1 | 399.8 | 399.8 | 389.1 |
| 6×6 | 1/2.74 | 2.74 | 16.9 | 17.0 | 17.0 | 16.9 | 523.4 | 536.1 | 536.1 | 523.4 |
Contact us for more specification
1.You are manufacturer or trader ?
We are a professional ISO certified cable manufacturer with more than 20 years experience.
2.How can I get the quotation of the products ?
Pls send your inquiry to us,our sales manager will offer you within 12 hours.
3.What does your company do regarding quality control?
1) All raw materials we selected are the highest quality. 2) Professional and skillful workers care every details in handling the producing. 3) Quality control department is specially responsible for quality checking in each process.
4.Do you provide OEM project service?
Yes,OEM & ODM order is warmly welcomed.Our engineers will give you the professional suggestions.
5.What is your payment term ?
Our payment term is usually T/T 30% in advanced, the balance before shipping or L/C at sight.
|
