200-6300A Low Voltage Electrical Busway System Dense Sandwich Bus Duct

Categories Sandwich Busduct
Certification: ISO9001
Place of Origin: Langfang, Hebei, China
Material: Copper
Protection Level: IP54/IP66
Rated frequency: 50Hz--60Hz
Color: Silvery
Name: Enclosed Busway
Use: Electric Power Transmission
Rated insulation voltage: 660V/1000V
Rated working voltage: 380V/660V
Brand Name: BZIDA
MOQ: 50 meters
Packaging Details: Export standard compliant
Delivery Time: 30 days
Payment Terms: 30% prepayment, full payment upon delivery
Supply Ability: 3000 meters per month
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

200-6300A Low Voltage Electrical Busway System Dense Sandwich Bus Duct

200-6300A Low Voltage Electrical Busway System Dense Sandwich Bus Duct Aluminium Busway


Product Description:

The thickness of steel plates is usually 1.5 to 2.0 millimeters (in millimeters); The aluminum magnesium alloy shell, unlike ordinary aluminum profiles, is carefully synthesized from alloy materials, and its thickness is thinner and lighter compared to ordinary materials.

Within the thickness range of 3.5 millimeters to 5 millimeters, the aluminum magnesium alloy shell exhibits excellent mechanical strength and dynamic thermal stability, far superior to steel plates. In addition, its surface treatment process is exquisite, without defects such as bubbles, cracks, marks, or oxidation, ensuring the firm adhesion of the spray coating and preventing it from peeling off.

Features:

Series matching and commercial production: Bus ducts have a series of product specifications and models to meet the needs of different users. At the same time, adopting a commercialized production method for bus ducts can greatly improve production efficiency and quality.

Small size and large capacity: The volume of the bus duct is relatively small, but the transmission capacity is large. This allows the bus duct to transmit more electrical energy in a limited space, improving the transmission efficiency of the power system.

Short design and construction period: Due to the modular design and standardized production of bus ducts, the design and construction period can be greatly shortened and the engineering efficiency can be improved.

Easy installation and disassembly: The installation and disassembly of bus ducts are very convenient, without the need for complex construction processes and a large number of maintenance personnel. This makes the bus duct more flexible and maintainable in the power system.

Technical Parameters:

Product Name
Electrical Busduct
Conductor
Copper or Aluminum Busbar
Rated Current
250A-6300A
Protection Level
IP54/IP66
Insulation Material
Epoxy or Polyester Film
Product Standard
IEC 61439-6:2012
OEM/ODM
Acceptable and Welcome
Application
Shopping Malls, Hotels, Factories, Hospitals, Apartments
Package
Wooden Cases

FAQ:

1.Are you a trade company or a manufacturer?

Baizida Electrical Equipment Co., Ltd is a production and sales-oriented enterprise focusing on the production of power equipment, integrating design, research and development, manufacturing and technical services.

2.What are the main products of your company?

Our company specializes in the production and sales of high-quality power equipment, including power distribution equipment, electrical products, generators, charging piles, frequency converters, etc. It is widely used in residential, commercial and industrial fields.

3.How do you ensure the quality of your products?

We strictly adhere to international standards and quality management systems. All products undergo rigorous testing and inspection before leaving the factory. We also offer a product quality guarantee period to ensure that the products you purchase meet your expected performance.

4.Do you offer customization services?

Yes, we can provide customized services according to the specific needs of our customers. Whether it's product specifications, design, or functionality, our technical team can work with you to develop solutions that meet your requirements.

5.Can you print our brand on the product?

Yes, of course, we also do OEM to print client’s brand on the product
