GYTA53 Double Sheath Steel Tape Armored Fiber Optic Cable Outdoor Direct Burial

Categories	Underground Fiber Optic Cable
Brand Name:	JQ/OEM/Customize
Model Number:	GYTA53
Certification:	ISO9001 ROHS CE-EMC FCC SDOC
Place of Origin:	Guangzhou, China
MOQ:	1km
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	4500KM Per Month
Delivery Time:	5-8 work days
Packaging Details:	wooden drum
Fiber type:	G652D Single mode or as your request
Color:	Black or orange or Customized
Jacket:	PE,MDPE,LSZH,PVC,HDPE
Fiber count:	4-288cores
Product name:	Double Sheath Steel Tape Armored Fiber Optic Cable GYTA53
Length:	2km or customized length
Installation:	Aerial & Duct
Oem:	Available
Application:	Telecommunication/Data Center/FTTH
Type:	Singlemode &Multimode/ MM/SM

Contact Now

Add to Cart

Company Info.

Guangzhou Jiqian Fiber Optic Cable Co., Ltd.

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

GYTA53 Double Sheath Steel Tape Armored Fiber Optic Cable Outdoor Direct Burial

Double Sheath Steel Tape Armored Fiber Optic Cable GYTA53 / Aluminum Armored Direct Buried Cable

The 250µm fibers are housed in PBT loose tubes filled with water-blocking gel. A central steel strength member supports the core, with tubes and fillers stranded around it for a compact structure. The core is wrapped with APL for moisture protection, followed by a PE inner sheath. PSP armor is applied longitudinally, and the cable is finished with a durable PE outer sheath for direct-burial environments.

Features

Has good mechanical properties and temperature characteristics.

Loose tube material itself has good water resistance and high strength.

The tube is filled with a special grease to protect the fiber.

The specially designed compact cable structure effectively prevents the casing from retracting.

PE jacket has excellent UV radiation resistance,ensure the waterproof performance of the cable.

Single wire center reinforcement core.The loose tube is filled with a special waterproof compound.

Full core filling.Plastic coated aluminum tape (APL) moisture barrier

Application

Suitable for directly buired laying method

Optical Characteristics

Items		Unit	Specification
Items		Unit	G652D
Mode Field Diameter	1310nm	um	9.2±0.4
Mode Field Diameter	1550nm	um	10.4±0.5
Cladding Diameter		um	124.8±0.7
Cladding Non-Circularity		%	≤0.7
Core-Cladding Concentricity Error		um	≤0.5
Coating Diameter		um	245±5
Coating Non-Circularity		%	≤6.0
Cladding-Coating Concentricity Error		um	≤12
Cable Cutoff Wavelength		nm	acc≤1260
Attenuation(max.)	1310nm	dB/km	≤0.36
Attenuation(max.)	1550nm	dBkm	≤0.22

Technical Parameters

GYTA53( Aluminium polyethylene laminate)

Fiber Count	Nominal Diameter (mm)	Nominal Weight (kg/km)	Allowable Tensile Load (N)		Allowable Crush Resistance (N/100mm)
Fiber Count	Nominal Diameter (mm)	Nominal Weight (kg/km)	Short Term	Long Term	Short Term	Long Term
2~30	13.2	162	3000	1000	3000	1000
32~48	13.8	175	3000	1000	3000	1000
50~72	14.6	205	3000	1000	3000	1000
74~96	16.0	230	3000	1000	3000	1000
98~144	17.6	285	3000	1000	3000	1000
＞144	Avaliable upon customer's request

Note : This datasheet can only be a reference, but not a supplement to the contract. Please contact our sales people
for more detailed information

Packing

1/2/3/4km or customized length export wooden drum

FAQ

1. Are you a trading company or manufacturer?
We are a manufacturer with 10+ years of experience, specializing in the R&D and production of fiber optic cables, drop cables, and patch cords. Our factory is located in Guangzhou—welcome to visit.

2. How is the quality ensured?
All fibers are fully tested before delivery. After price confirmation, free samples are available for quality checking.

3. Do you accept small orders?
Yes. Small orders are welcome, and we support customers’ new projects.

4. What is the delivery time?
Typically 3–7 working days depending on order quantity. We arrange shipment as soon as payment is received.

5. Do you offer OEM service?
Yes. We can print your logo and support various OEM/ODM customization ideas.
