| Categories | 15kwh Lithium Battery |
|---|---|
| Brand Name: | LCNE |
| Max Load Quantity(cells): | 16 |
| Battery Type: | Liquid |
| Cycle Life: | 8000 cycles |
| Dimension (L*W*H): | 926.5*450*265mm |
| Application: | Uninterruptible Power Supplies, Solar Energy Storage Systems, Electric Power Systems |
| Model Number: | LC-LM51314 |
| Weight: | 128KG |
| Operating Temperature(℃): | -20~+55℃ |
| Place of Origin: | Guangdong, China |
| Cathode Materials: | LiFePO4 |
| OEM/ODM: | Accepatable |
| Capacity: | 314Ah/200Ah/100Ah/280Ah/300Ah |
| Communication Port: | CAN2.0/RS485/WIFI/Bluetooth |
| Product name: | Lithium Iron Phosphate Lifepo4 Battery |
| Voltage: | 48V/51.2V |
| Keywords: | DIY Lifepo4 Battery Box |
| Battery cell: | 3.2V 100Ah Prismatic LiFePO4 Cell |
| Certification: | CE/RoHS/UN38.3/MSDS |
| Warranty: | 5-10 Years |
| Apllication: | Solar Energy Storage Sysytem |
| MOQ: | 10 |
| Price: | $899-930 |
| Company Info. |
| Guangdong Langchuan New Energy Technology Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
Product Parameter | |
Model | LC-LM51314 |
Battery Chemistry | LiFePO4 |
Normal Voltage | 51.2V |
Operating Voltage | 46~56V |
Energy Capacity | 16.08 KWh |
Standard Charge Current | 157A |
Standard Discharge Current | 157A |
Max Charge Current | 200A |
Max Disharge Current | 200A |
Other Parameter | |
Recommend Depth Of Discharge | 80% |
Dimensions(L/W/H) | 926.5*450*265mm |
Weight Approximate | 118Kg |
Package Dimensions(L/W/H) | 1000*525*435mm |
Gross Weight | 137Kg |
IP Rating Of Enclosure | IP20 |
Working Temperature | Charge:0°C~55°C Discharge:-209C~55°C |
Storage Temperature | -30°C~60°C(humidity ≤75%ROH) |
Humidity | 5%~95% |
Altitude | ≤2000m |
Cycle Life | 6000(25°C 0.5C 80%SOH) 8000(25°C 0.5C 70%S0H) |
Communication Port | CAN2.0 RS485 |
Wireless Communication | Bluetooth, WIFl |
Certification | CE-EMC, MSDS,UN38.3 |
Custom Solutions & Capabilities | ||
Color | White, Black, Blue, Gray | |
Capacity | 50Ah, 75Ah, 100Ah, 200Ah, 280Ah, 314Ah, 400Ah | |
Voltage | 12.8V, 25.6V, 48V, 51.2V, 60V, 72V, 96V, 120V | |
Energy | 2.5KWh, 5kWh, 10kWh, 15kWh, 16kWh, 20kWh, 30kWh, 50kWh | |
BMS | Bluetooth BMS, WiFi BMS, 4G BMS, Active Balance | |
Shell Material | ABS Plastic, Aluminum Alloy, IP65 Waterproof | |
Logo | Laser Engraving, Silk Printing, Label Sticker | |
Packaging | Wooden Case, Carton Box, Pallet with Foam Protection | |
Q1: Can I order samples? |
A1: Yes, we welcome to order samples to test and check the quality. |
Q2: How to ensure the quality of your battery cells? |
A2: Our batteriey cells are all grade new A. We are ready to accept third-party inspections at any time. If
the cells are not brand-new Grade A, we will provide full compensation. |
Q3: What about the delivery time? |
A3: Samples will take 3 days, and mass production time will take 2-5 weeks, depending on the order quantity. |
Q4: Can I print my logo on the product? |
A4: Yes. Please inform us formally before production, and first
confirm the design based on our samples. |
Q5: Does the shipping way to our country include tax? |
A5: It depends on the country and the shipping way you choose. Most
Asian countries, most European countries, the United States,and
Canada have tax-included shipping channels. |
Q6: How long is the warranty? |
A6: Our warranty is 10 years. Free replacement for the first five years, and free maintenance
for the next five years. |
