0.01mm Pore PVDF Hollow Fiber Membrane 29M2 Surface Area For Water Treatment Systems

Categories MBR Membrane
Brand Name: SINOMEMB
Model Number: SNU-HO-2-D1020AN
Certification: NSF
Place of Origin: China
MOQ: 5
Packaging Details: Standard export packaging
Core Components: MBR
Product name: hollow fiber ultrafiltration membrane, ultrafiltration system, PVC Hollow fiber UF membrane module
Pore size: customized., from 1μm to 0.05μm, 0.01micron, 1.0μm, 0.2μm
Usage: Waste water treatment, , Liquid Filter, remove bacterias, Purification
Module: Out-inside
Nominal Pore Size: 0.01 μm
Size: 216×1120mm
Surface Area: 29 m2
Filtration Methods: Outside-in
Package: Plastic bags
Product Type: Skincare
Application: Apply a few drops to clean skin, morning and evening
Ph Range: 2-11
Membrane Materials: PVDF
Work Pressure: 0.02-0.04MPa
Backwash Flux: 30-50 LMH
Temperature Range: 5-40°c
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

0.01mm Pore PVDF Hollow Fiber Membrane 29M2 Surface Area For Water Treatment Systems

UF membrane element size



The normal start-up and normal cleaning and maintenance of the UF system are the key to ensure the long-term normal use of membrane products. Before starting the system, it should be ensured that the parameters of each valve, instrument, pre-processing equipment, signal transmission equipment, power equipment, etc. meet the design specifications and requirements, so as to ensure the safe, stable and up-to-standard operation of the overall system. Please refer to the product technical manual for the debugging and testing work of the system in the early stage.

Disclaimer

Failure to operate in strict accordance with the operating limits and guidelines set forth herein voids our limited warranty. If the UF system is out of service, please inject protective liquid inside the membrane module for anti-corrosion treatment, so as to avoid the increase of maintenance cost caused by the large number of microorganisms in the system.

Partial OEM model parameters of SINOMEMB ® UF membrane

UF specifications and models Membrane material Operation mode Membrane element size (mm) Effective membrane area (㎡) Nominal filter pore size (μm)
SNU-HO-2-D1020AN PVDF outside-in Φ216×1120 29 0.01
SNU-HO-2-SP40 PVDF outside-in Φ160×1804 40 0.03


Note: The element model (membrane performance, appearance size) not mentioned can be customized according to the order quantity.

Specification List I
Model
MBR
-020-1-30
MBR
-020-1-20
MBR
-015-1-20
MBR
-015-1-15
MBR
-010-1-125
MBR
-010-1-10
Effective area(m2)
30
20
20
15
12.5
10
Size: H*L*W(mm)
2000*535*46
2000*535*46
1500*535*46
1500*535*46
1000*535*46
1000*535*46
Pore Size (um)
0.03
0.2
0.03
0.2
0.03
0.2
Fiber Diameter (mm)
2.0土0.025
2.5土0.025
2.0土0.025
2.0土0.025
2.0 + 0.025
2.5 + 0.025
Flux rate (L/m2.hr)
10~30
Membrane Material
Reinforced PVDF + ABS
Connector Material
ABS
Fiber Tensile (N)
200
Bubble Point (Mpa)
>0.05
Specification List II
MBR membrane has stainless steel tubes on each side. They act as the membrane's supporting material and water collection pipes. Compared with other styles of the MBR Membrane, Water Master is easier, more convenient to assemble on the cassette, and easier to disassemble for further maintenance and replacement. It is the ideal choice for bigger projects.
Model
SP-MBR-Il-40
SP-MBR-Il-25
SP-MBR-II-20
SP-MBR-I-15
SP-MBR-II-06SP-MBR-Il-10
MBR
-010-1-10
Effective area(m2)
30
20
20
15
12.5
10
2000*1250*30Size: H*L*W(mm)
2000*535*46
1500*1250*30
1500*535*46
1500*535*46
1000*535*46
1000*535*46
Pore Size (um)
0.03
0.2
0.03
0.2
0.03
0.2
Fiber Diameter (mm)
2.0土0.025
2.5土0.025
2.0土0.025
2.0土0.025
2.0 + 0.025
2.5 + 0.025
Flux rate (L/m2.hr)
10~30
Membrane Material
Reinforced PVDF + ABS
Connector Material
ABS
Fiber Tensile (N)
200
Bubble Point (Mpa)
>0.05
