Size 0.35mm*0.8mm Enameled Copper Flat Wire

Categories	Rectangular Copper Wire
Brand Name:	RVYUAN
Model Number:	AIW220
Certification:	UL/ISO9001/ISO14001/RoHS/Reach
Place of Origin:	China
MOQ:	10kg
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	100kg/week
Delivery Time:	7 days
Packaging Details:	Carton
Contuctor Type:	Solid
Material:	Copper
Shape:	Rectangular
Width:	0.8mm
Type:	Insulated
Certificates:	ROHS/UL/SGS/ISO9001:2008
Product name:	Size 0.35mm*0.8mm Enameled Copper Flat Wire
Thickness:	0.35mm

Contact Now

Add to Cart

Company Info.

Tianjin Ruiyuan Electric Material Co,.Ltd

Verified Supplier

View Contact Details

Product List

Haven't found right suppliers
Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
And this service is free of charge.
we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!

Submit Buying Request

Product Details
Company Profile

Size 0.35mm*0.8mm Enameled Copper Flat Wire

Our enameled rectangular copper wire is versatile and designed to improve the efficiency of a wide range of energy devices. Trust our expertise and let our high-quality products elevate your projects to new heights. We are committed to providing exceptional quality and performance, so you can be confident that our enameled rectangular copper wire will meet or exceed your expectations in any electrical application.

Item		conductor dimension		Insulation thickness		Overall dimension		Breakdown voltage	Conductor resistance
Item		Thickness	Width	Thickness	Width	Thickness	Width	Breakdown voltage	Conductor resistance
Unit		mm	mm	mm	mm	mm	mm	kv	Ω/km 20℃
SPEC	Nominal	0.350	0.800	0.025	0.025
	Max	0.359	0.860	0.040	0.040	0.400	0.900		72.710
	Min	0.341	0.740	0.010	0.010			0.700
No. 1		0.347	0.814	0.010	0.015	0.367	0.843	1.005	63.154
No. 2								1.414
No. 3								1.336
No. 4								1.558
No. 5								1.652
No. 6
No. 7
No. 8
No. 9
No. 10
Avg		0.347	0.814	0.010	0.015	0.367	0.843	1.393
No.of reading		1	1	1	1	1	1	5
Min. reading		0.347	0.814	0.010	0.015	0.367	0.843	1.005
Max. reading		0.347	0.814	0.010	0.015	0.367	0.843	1.652
Range		0.000	0.000	0.000	0.000	0.000	0.000	0.647
