304 Stainless Steel Lab Fume Hood with All Steel Construction and Customizable Size for Chemical Institutes

304 Stainless Steel Lab Fume Hood with All Steel Construction and Customizable Size for Chemical Institutes

304 Stainless Steel Lab Fume Hood with All Steel Construction and Customizable Size for Chemical Institutes
304 Stainless Steel Lab Fume Hood with All Steel Construction and Customizable Size for Chemical Institutes
Categories Lab Fume Hood
Place of Origin: Guangdong, China
Brand Name: ZhiJian
MOQ: 2
Price: $900-1,100
Material: 304 Stainless Steel
Worktop Material: 12.7mm solid core physical and chemical board
Lining Material: 5mm thick Compete board
Window Glass: 5mm tempered glass
Face Wind Speed: 0.3-0.5m/s
Noise Level: <60 dB
Illumination: 12W fluorescent lamp X1
Exhaust Volume Max: 2074m3/h
Exhaust Volume Min: 180m3/h
Safe Opening Size: 750mm
Work Open Max: 600mm
Work Open Min: 150mm
Physical Dimension: 1800*800*2350 mm
Work Surface Size: 1550*645 mm
Deflector Design: Rivet-free, adjustable angle
Contact Now
Company Info.
Guangdong Zhijian Experimental Equipment Technology Co., Ltd.
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

304 Stainless Steel Lab Fume Hood with All Steel Construction and Customizable Size for Chemical Institutes

Products Description
Basic Parameters
Model
Model
Model
1
Fume Hood Model
HT1200*800*2350
HT1500*800*2350
HT1800*800*2350
2
Design/Production Basis
National Machinery MinistryJB/T6452-1999
3
Physical Dimension（L*W*H）mm
1200*800*2350
1500*800*2350
1800*800*2350
4
Work Surface Size
950*645
1250*645
1550*645
5
Safe Maximum Opening Size
750mm
5-1
Exhaust Volume
1296m3/h
1685m3/h
2074m3/h
6
Work Open Maximum Size
600mm
6-1
Exhaust Volume
1080m3/h
1404m3/h
1728m3/h
7
Working Open Minimum Size
150mm
7-1
Exhaust Volume
180m3/h
234m3/h
280m3/h
8
Illumination
12W fluorescent lamp X1
9
Face Wind Speed
0.3-0.5m/s
10
Noise
<60 dB
11
Work Surface
12.7mm solid core physical and chemical board, the countertop has the characteristics of no delamination, strong acid and alkali resistance, moisture resistance, high temperature resistance, and repairability.
12
Operating Area（On the cabinet）
Steel structure, one-time bending of 1.0mm steel plate
12.1
Lining Material, Thickness
5mm thick, Compete board. This sheet has passed the corrosion test of more than 100 chemicals (including sulfuric acid and nitric acid) carried out by the Pisburg laboratory.
12.2
Deflector Material Thickness
The installation of the deflector adopts a rivet-free design, and the installation position and angle can make the exhaust evenlydistributed, and there is no dead angle. Under standard conditions, the ratio of air volume above the deflector to the middle andbottom outlets is about 50±10%, ensuring that gases of different specific gravity can be effectively discharged
12.3
Console Window Door
The exterior trim panel above the window door is provided with a natural air supply outlet, the overall glass window can be pushedup and down, and the window glass is transparent 5mm tempered glass. The sliding glass door is fully open up to 720mm, and thereis a logo at the opening 2/3. Stepless balance design, the door can be parked at any position
Product Description
Detailed Images




PP Material Fume Hood





All Steel Fume Hood






HT—I Ventilation





Floor Type Fume Hood






Supplementary Ai

Fume Hood on Top
Related Products
$15 - $ 20 Pieces
100 Pieces (MOQ)
$15 - $ 20 Pieces
100 Pieces (MOQ)
$15 - $ 20 Pieces
100 Pieces (MOQ)
Packing&Shipping
Company Introduction
Guangdong Zhijian Experimental Equipment Technology Co., Ltd. is an engineering company engaged in the integration of laboratory construction planning, design, production, construction and after-sales tracking services.

Guangdong Zhijian Experimental Equipment Technology Co., Ltd.

Since its establishment, it has been committed to the design, development and manufacture of laboratory basic equipment, adhering to the design concept of modern laboratories in Europe and the United States, the designed products are not only durable, functional, flexible, beautiful, but also more user-friendly and safety. The real products have been successfully exported to large and medium-sized laboratories in more than 20 countries and regions around the world, such as colleges and universities, hospitals, disease control centers, chemical companies, testing institutions, research and scientific research, and won customers with excellent quality and service. unanimously recognized and admired.
FAQ
Q1 why choose us? A: 1. We have our own factory and ISO14001, ISO45001, ISO9001 and other certificates 2. Quality assurance and 24-hour service 3. Professional and excellent design, production, transportation and engineering management team 4. Our company was established in 2014, specializing in laboratory furniture, equipment, ventilation system, exhaust emissions, laboratory decoration has rich experience 5. Provide one-stop procurement of laboratory equipment and furniture to provide you with satisfactory products 6. Can provide you with professional suggestions or opinions for your reference Q2 Can I visit your factory? A: It's very welcome. Our factory is located in Guangzhou, an important central city in China, an international business center and A comprehensive transportation hub. Q3 Do you have samples? A. We are happy to supply sample blocks. Q4 Can I choose another color? Custom size? A: You can choose any color, and the size can be customized according to your needs. Q5 What about your quality assurance?

A: All our products are made of high quality raw materials and have been tested. Most of the workers in our factory are very experienced.
