Stable Molten Pool Blue Light Composite Laser Welding Machine With Almost No Spatter

Categories Industrial Laser Welding Machine
Brand Name: HanWei
Model Number: HW-B
Certification: CE
Place of Origin: Shenzhen, China
MOQ: 1 Set
Price: USD / Set
Payment Terms: T/T
Supply Ability: 2000 Sets / year
Delivery Time: 10 working days
Packaging Details: Export Plywood Packing
Laser Power: 1000W
Wavelength (nm): 445nm
Gas Type: Co-axial / Side Gas
Operating Temperature (℃): 5-40
Head Structure: T / F/ Y
Core Diameter: 200 μm / 0.22 NA
Welding Materials: Copper / Gold / Silver
Cooling Method: Water Cooling
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

Stable Molten Pool Blue Light Composite Laser Welding Machine With Almost No Spatter

Stable Molten Pool Blue Light Composite Laser Welding Machine With Almost No Spatter
To address the challenge that high-reflection metals like copper, gold, and silver barely absorb energy from conventional lasers, the blue laser hybrid welding machine adopts short-wave blue laser technology to achieve significantly higher energy coupling efficiency. Even for highly conductive and thermally conductive materials, it can rapidly form a stable molten pool, greatly reducing risks such as cold lapping and lack of fusion. It is widely used in power battery busbars, precision electronic contacts, conductive connectors, and other fields.

The machine equipped with an intelligent wobble welding system, which enhances molten pool fusion and improves weld bead filling performance. It supports thin-sheet precision welding, gap-bridging welding, deep penetration welding, and other applications, significantly expanding the scope of processing.
Blue Laser Welding Machine
Key Features
  1. Specialized in Welding High-Reflection Materials Such as Copper, Gold, Silver, etc.
  2. Hybrid Technology and Wobble Control System.
  3. Lower Energy Threshold for Precise Control.
  4. Stable Molten Pool with Almost No Spatter.
  5. Deeper Penetration and Superior Weld Structure.
Technical Parameters
ModelHW-B
Laser Power1000 W
Wavelength(um)445 nm
Head OptionBlue Laser Hybrid
Laser Core50um / 100um
Head Weigh4 Kg
FocusesOption
Laser BeamStationary / Wobble
Cooling MethodWater Cooling
Machine Size1000*450*850mm
Power Range10-100
Power Instability (%)< 3
Core Diameter200 μm / 0.22 NA
Applications

Thanks to precise energy distribution and controlled molten pool dynamics, the welding process is clean and smooth with nearly zero spatter. No secondary cleaning around the weld is required, reducing labor and time costs and improving overall line automation efficiency.

The high absorption rate of blue laser in copper-based materials allows heat to penetrate the welding zone more effectively, forming dense and uniform weld microstructures. The welds feature high strength and stable penetration, meeting the requirements of high-current-carrying and high-reliability industrial applications.

Welding Samples

Shenzhen Hanwei Laser Enterprise
Shenzhen Hanwei Laser Equipment Co., Ltd. provides a diverse portfolio of laser systems, including benchtop and portable configurations. These solutions integrate advanced fiber, pulsed or continuous-wave, blue laser, diode laser, and hybrid laser technologies, each carefully developed to fulfill customers’ individual demands.

The company delivers personalized solutions for targeted application scenarios, supported by professional guidance and comprehensive after-sales services, helping customers fully optimize the performance of their laser equipment. With branches and affiliated organizations across Europe, North America, Asia, and the Middle East, Hanwei Laser has formed a widespread global network to serve users worldwide.

Laser welding remains the core competency of Hanwei Laser. The company is devoted to providing forward-looking laser welding technologies for global laser integration enterprises, aiming to offer premium welding solutions for every integrator. As one of the few enterprises worldwide holding both national high-tech and specialized, sophisticated, distinctive and innovative certifications, it focuses on the full industrial chain including R&D, manufacturing, and marketing of various welding lasers, laser control systems, laser optical systems, and laser welding processes.
