Walk-in Temperature and Humidity Test Chambers
Laboratory Walk-in Temperature Test Chambers consist of Control
Panel, electrical panels, moisturizing plate blower, heater,
humidifier, and freezer. These chambers provide large testing space
for temperature and humidity testing of large-scale parts and
semi-finished products. Ideal for testing computer terminals,
vehicle parts, and other large or high-quantity products.
Technical Specifications
| Model | THR-volume (low-temperature options: A ~ F) |
|---|
| Inner Dimensions | Customer designated space size and design |
|---|
| Temperature Range | Low Temperature (A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C)
High Temperature: 80°C (80°C ~200°C optional) |
|---|
| Humidity Range | 20%~98% R.H. (10%-98% R.H. / 5%-98% R.H. special optional with
dehumidifier) |
|---|
| Temperature Rising/Falling Velocity | Temperature rising: approx. 0.1~3.0°C/min
Temperature falling: approx. 0.1~1.0°C/min
(Minimum 1.0°C/min falling velocity optional) |
|---|
| Optional Accessories | Slope for cart, Recorder, Water Purifier, Dehumidifier |
|---|
| Compressor | French Tecumseh Brand, Germany Bizer Brand |
|---|
| Power | AC 380 V(±10%), 50/60HZ, 3 ph 5 Lines |
|---|
Compliance Standards
- GB11158 Technical conditions for high-temperature testing room
- GB10589-89 Technical conditions for low-temperature testing room
- GB/T10586-89 technical conditions for humidity testing room
- GB/T2423.1-2001 testing methods for low-temperature
- GB/T2423.2-2001 testing methods for high-temperature
- GB/T2423.3-93 technical conditions for humidity testing room
- GB/T2423.4-93 testing method for alternating hot and humid
- IEC60068-2-1.1990 testing methods for low-temperature
- IEC60068-2-2.1974 testing methods for high-temperature
- GJB150.3 High-temperature test
- GJB150.4 Low-temperature test
- GJB150.9 muggy test
- GB/T2423.22 temperature test
Product Gallery
Chamber Details
Quality Certifications
Passed the ISO9001:2008 quality system authentication and ROHS
authentication.
Company Overview
Packing & Delivery
Packing Details: Export standard plywood case
Delivery Details: 30 days after order
Our Customers
Key Features
- Graceful appearance, circularly shaped body, surface treated with
mist strips
- Easy to operate, safe and reliable operation
- Rectangular double-paned viewing window with interior lighting
- Double-layer-insulated airtight doors for effective temperature
insulation
- Externally connectable water supply system with automatic recycling
- French Tecumseh compressor with environmentally friendly
refrigeration (R23 or R404A)
- LCD display screen showing measured values, set values, and time
- Multiple segment program editing with quick or ramp rate control
- Mobility casters with strong positioning screws
Testing Data & Parameters
Display Mode: LCD display, touch control
Display Accuracy: temperature 0.1%, humidity 0.1%
Set Accuracy: temperature 0.1℃, humidity 0.1%
Display Resolution: temperature 0.1℃, humidity 0.1%
Sampling Time: 1 time/S
Graphical Display: Full display of setting and program curve
Program Capacity: Max. 100 programs, each program with 50 segments, max. 999 cycles
Multi-Protection Functions
- Grounded protection
- Leakage/breakage protection
- Heater short-circuit protection
- Blower motor overload protection
- Refrigerator over-voltage protection
- Refrigerator overload protection
- Water shortage protection
Frequently Asked Questions
1. How can I get the price?
We usually quote within 24 hours after we get your inquiry (except
weekends and holidays). For urgent pricing requests, please contact
us directly.
2. What is your lead time?
Lead time depends on order quantity and season. Typically, we ship
within 7-15 days for small quantities and about 30 days for large
quantities.
3. What is your payment term?
T/T, Western Union, MoneyGram, and Paypal. Payment terms are
negotiable.
4. What is the shipping method?
Shipping options include sea, air, or express (EMS, UPS, DHL, TNT,
FEDEX, etc.). Please confirm shipping method before placing orders.
5. How do you maintain long-term business relationships?
We maintain good quality and competitive pricing to ensure customer
benefits. We respect every customer and sincerely conduct business
while building lasting relationships.
For more information about our Walk-in Temperature Test Chambers,
please don't hesitate to send your inquiry.
