Test Weight Water Bags Adjustable Reusable Tear Resistant Quick Inflation
Description
Hongruntong Marine crane load testing water bags are flexible, high-capacity proof load devices specifically developed for marine cranes, offshore lifting systems, and heavy industrial hoisting equipment. Constructed from multi-layer reinforced PVC fabrics, these bags deliver excellent tensile performance while remaining lightweight when empty.
Their modular configuration allows easy handling and rapid deployment. Integrated safety valves, reinforced lifting lugs, and calibrated filling systems ensure accurate load simulation. These water bags significantly enhance testing safety while lowering transport and operational costs.
Case Study – Floating Crane Commissioning
During commissioning of a 200-ton floating crane in a Middle Eastern shipyard, traditional test weights posed transport challenges. Hongruntong supplied a set of interconnected water bags totaling 220 tons.
The modular setup allowed staged loading. Testing finished ahead of schedule, reducing crane commissioning time by two days. Engineers highlighted improved safety margins and simplified logistics.
Specifications
| Name | Crane Load Test Water Bags |
| Application | Proof Load Testing, Offshore Load Testing, Structural Load Testing, Ship Load Testing, Industrial Equipment Testing, Research and Development. |
| Content | 100% POLYVINYL CHLORIDE |
| Phthalate | 7P Phthalate Free (includes all Phthalates listed in CAL Prop 65, CPSIA and REACH) |
| Backing Material Size | 1.8/2.0 Mm X 1.55m, Thickness Produced as Per Your Request. |
| Weight | 37.1 oz square yard/ 1450 +- 50 GSM |
| Special | UV Resistant |
| 7P Phthalate Free (includes all Phthalates listed in CAL Prop 65, CPSIA and REACH) | |
| BPA Free / Tris Free / Formaldehyde Free | |
| Does Not Contain Conflict Minerals | |
| Care Instructions | Rinse with Fresh Water and Air Dry |
| Do Not Store with Seawater and Keep Away From Heat Sources | |
| Available sizes | 5000 kg |
| 8,000 kg | |
| 1,0000 kg | |
| 15,000 kg | |
| 20,000 kg | |
| 30,000 kg | |
| 50,000 kg | |
| 100,000 kg | |
| Special Sizes Could be Customized | |
| OEM | Supported |
| MODEL | Weight | Volume | Empty Height (Length) | Filled Height (Length) | Max Diam (ø) | Dry Weight without accessories |
| kg | Liters / m3 | m | m | m | kg | |
| lbs | USG | ft | ft | ft | lbs | |
| HM-1T | 1,000 | 1,000 / 1 | 2.52 | 2.23 | 1.39 | 36 |
| 2,204 | 264 | 8.27 | 7.33 | 4.56 | 80 | |
| HM-2T | 2,000 | 2,000 / 2 | 2.87 | 2.6 | 1.65 | 41 |
| 4,409 | 528 | 9.41 | 8.5 | 5.43 | 90 | |
| HM-3T | 3,000 | 3,000 / 3 | 3.38 | 2.97 | 1.82 | 50 |
| 6,613 | 792 | 11.11 | 9.75 | 6.0 | 110 | |
| HM-4T | 4,000 | 4,000 / 4 | 3.41 | 3.07 | 1.88 | 64 |
| 8,818 | 1,056 | 11.22 | 10.1 | 6.16 | 141 | |
| HM-5T | 5,000 | 5,000 / 5 | 4.14 | 3.52 | 2.13 | 80 |
| 11,023 | 1,320 | 13.60 | 11.58 | 7.0 | 176 | |
| HM-6T | 6,000 | 6,000 / 6 | 4.39 | 3.91 | 2.28 | 86 |
| 13,227 | 1,585 | 14.41 | 12.83 | 7.48 | 189 | |
| HM-8T | 8,000 | 8,000 / 8 | 4.54 | 3.93 | 2.52 | 104 |
| 17,636 | 2,113 | 14.91 | 12.91 | 8.27 | 230 | |
| HM-10T | 10,000 | 10,000 / 10 | 5.18 | 4.49 | 2.70 | 130 |
| 22,046 | 2,641 | 17.0 | 14.75 | 8.90 | 286 | |
| HM-12.5T | 12,500 | 12,500/ 12.5 | 5.43 | 4.62 | 2.86 | 154 |
| 27,558 | 3,302 | 17.91 | 15.16 | 9.39 | 340 | |
| HM-15T | 15,000 | 15,000 / 15 | 6.24 | 5.48 | 2.95 | 159 |
| 33,069 | 3,962 | 20.50 | 18.00 | 9.70 | 350 | |
| HM-20T | 20,000 | 20,000 / 20 | 6.78 | 6. 04 | 3.42 | 224 |
| 44,100 | 5,283 | 22.25 | 19.83 | 11.25 | 492 | |
| HM-25T | 25,000 | 25,000 / 25 | 7.51 | 6.40 | 3.75 | 315 |
| 55,115 | 6,604 | 24.66 | 21.0 | 12.33 | 695 | |
| HM-35T | 35,000 | 35,000 / 35 | 8.07 | 7.11 | 3.91 | 417 |
| 77,161 | 9,246 | 26.50 | 23.33 | 12.83 | 920 | |
| HM-40T | 40,000 | 40,000 / 40 | 8.71 | 7.72 | 4.07 | 440 |
| 88,184 | 10,566 | 28.58 | 25.33 | 13.36 | 970 | |
| HM-50T | 50,000 | 50,000 / 50 | 8.99 | 7.77 | 4.56 | 544 |
| 110,231 | 13,208 | 29.50 | 25.50 | 14.96 | 1200 | |
| HM-100T | 100,000 | 100,000 / 100 | 11.27 | 10.00 | 5.65 | 952 |
| 220,462 | 26,420 | 37.00 | 32.9 | 18.56 | 2100 |
Features
Advanced Multi Layer Fabric Technology
The bag body integrates multiple reinforcement layers, enhancing
puncture resistance and fatigue strength. This structure ensures
stability during repeated filling cycles and heavy lifting
conditions.
Temperature Adaptability
Materials maintain flexibility across a wide temperature range,
from cold offshore climates to tropical shipyards. Crack resistance
and coating stability ensure long service life.
Optimized Filling/Draining System
Large diameter valves accelerate filling and draining, reducing
operational time. Transparent level indicators assist operators in
precise load monitoring.
Compact Storage Design
Foldable construction reduces storage footprint dramatically
compared with steel weights, ideal for offshore logistics.
Applications
Dry Dock Testing Operations
Used during ship repair periods to verify onboard cranes without
removing equipment.
Renewable Offshore Energy Projects
Applied in wind farm installation vessels to test heavy lifting
systems.
Industrial Crane Inspection
Also suitable for construction cranes requiring proof load
certification.
Why Choose Hongruntong Marine
Dedicated Marine Equipment Manufacturer
Focused exclusively on marine testing equipment, ensuring deep
technical expertise.
Flexible Custom Production
Tailored sizes, shapes, lifting configurations, and instrumentation
available.
Global Delivery Experience
Efficient logistics network ensures timely international delivery.
Comprehensive Documentation
Technical manuals, inspection certificates, and operation
guidelines included.
FAQ
1. How long does a test typically take?
Usually several hours depending on bag capacity and water source.
2. What maintenance is required?
Cleaning, drying, and periodic visual inspection are recommended.
3. Are spare parts available?
Yes, valves, hoses, and fittings can be supplied.
4. Is operator training required?
Basic training is recommended for safe handling.
5. Can bags be repaired if damaged?
Minor damage can usually be professionally repaired.




|
