LMW-5 Dry & Wet Dental Milling Machine: Dual-Mode Cutting for Zirconia/PMMA/Titanium High Precision 5 Axis Dental Prosthetic Milling Equipment

Categories Dental Equipment
Brand Name: Leomed
Model Number: LMD-5
Certification: CE
Place of Origin: China
MOQ: 1
Price: 13000 USD
Payment Terms: T/T
Supply Ability: 10
Delivery Time: 7
Packaging Details: Wooden Boxes
Input Power supply: Single-phase AC 220V 50/60Hz
Power: 3.7KW
Air supply pressure: 6Bar
Spindle Power: AC 2.5KW
Cooling method: Water cooling
Speed: 60,000 rpm
Collet: Φ 6mm
Route X,Y,Z axis: 160x115x105mm
A,B axis: A:±360° B:+90°,-30°
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

LMW-5 Dry & Wet Dental Milling Machine: Dual-Mode Cutting for Zirconia/PMMA/Titanium High Precision 5 Axis Dental Prosthetic Milling Equipment

LMW-5 Wet & Dry Milling Machine


1.Core Functions

1.1 Machine Structure


Mineral cast integrated body combined with semi fixture design, delivering exceptional stability and shock resistance
for consistent high-precision machining,while enabling fast loading and precise positioning.


1.2 Cutting & Calibration System




- Dual cutting modes: Dry milling & wet milling supported (flexible adaptation to different material processing needs)
- 90-degree milling supported for complex dental prosthetics
- Industrial automatic calibration system with ±0.05 mm positioning accuracy
- High repeatability and long-term precision stability


1.3 Spindle Performance



- High-power dedicated spindle
- Water cooling system for sustained heavy-duty operation
- Max spindle speed: 60000 rpm
- High cutting efficiency, smooth surface finish, and extended service life


1.4 Intelligent Control Functions



- Compatible with all mainstream CAM software
- Breakpoint resume function supported
- Tool magazine life monitoring & real-time wear alerts
- After-sales diagnostic board for fast troubleshooting and maintenance


1.5 Fixture & Machining System



-Semi fixture design for fast loading and precise positioning

-5-axis configuration with defined rotary axis range (A ±360°, B +90° to -30°)

-DryWet Conversion System: Fully supported (switch freely between dry and wet milling modes)

-Working area: 160×115×105 mm

-Tool diameter compatibility: Ø6 mm


1.6 Dry & Wet Switching System

-Manual switching between dry and wet milling modes, simple operation logic that aligns with professional processing habits, enabling targeted adaptation to different material characteristics.
-Matching Water Tank: Equipped with a dedicated water storage tank for wet cutting, featuring a sealed structure to prevent leakage and facilitate easy refilling and cleaning; ensures stable water supply during continuous wet milling operations.
-Professional Water Chiller: Configured with a matching water chiller to maintain constant cooling water temperature. It effectively reduces tool wear, improves machining precision, and ensures a smooth surface finish of workpieces, especially suitable for processing heat-sensitive materials.


2.Processing Compatible Plates

2.1 Processable Materials



Ti Zirconia
Pre-milled Blank Glass Ceramic


Smooth milling, minimal chipping, and ideal for dental prosthetic manufacturing.


2.2 Holder Specifications

Number of axes
5
Millable material
Zirconia/PMMA/Wax/Glass ceramic/Titanium disc/Titanium abutment
Processing methodDry & Wet Milling
Dimension525×700×784 mm
Weight150 kg
Automatic tool change quantity18 tools


Support & Services

1. Application Scenarios

Digital dental laboratories, centralized prosthetic milling centers, dental clinic manufacturing hubs, and industrial precision milling workshops requiring multi-material processing.

2. Recommended Compatible Zirconia

Leomed 3D pro ML zirconia blocks optimized for this milling machine – improved machining stability, higher success rate, and consistent final quality.

3. Certifications

CE, ISO and other applicable industry certifications.
