High Speed 15-16m/Min Roller Shutter Roll Forming Machine PLC Control System

Categories Roller Shutter Door Roll Forming Machine
Place of Origin: CHINA
Brand Name: HENGFU
MOQ: 1 Piece
Packaging Details: Plastic Film & Steel Wire Fixed
Delivery Time: 45Days
Payment Terms: 30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment
Tile Type: Galvanized Steel / Color Steel
Certification: CE, SGS
Condition: New
Customized: Customized
Usage: Roller Shutter Door, Garage Door
Transmission Method: Gear Transmission
Control System: PLC
Transport Package: Plastic Film & Steel Wire Fixed
Hydraulic Pump Power: 4kw
Main Motor Power: 4kw
Frame Thickness: 16mm Wall Plate
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

High Speed 15-16m/Min Roller Shutter Roll Forming Machine PLC Control System

Easy Operation Fully Functional Roller Shutter Door Roll Forming Machine

The Roller Shutter Door Roll Forming Machine is a specialized, high-performance production line built exclusively for the door manufacturing and construction sectors. Designed for continuous, efficient operation, it produces premium roller shutter door profiles, offering modern workshops a fully automated and reliable solution to meet growing market demands.

Built with industrial-grade durability in mind, the machine features a robust frame constructed from 80×80 square tubes, paired with 15 forming stations for consistent molding. Critical components include a 16mm thick wall plate and Φ50mm solid 45# steel main shafts, delivering exceptional rigidity that withstands long hours of high-intensity production.

Its power and drive system ensures smooth, stable operation, utilizing a reliable gear transmission, a 4kW main motor, and a 4kW air-cooled hydraulic station. This setup supports a production speed of 15-16m/min, significantly boosting output efficiency and shortening manufacturing lead times.

Precision and usability are central to its design. It uses post-forming double-blade shearing for clean, burr-free cuts, controlled by a Delta PLC and frequency converter to achieve a length tolerance of ≤1mm. Additional features like 35mm galvanized pull rods, a Type 4 cycloidal reducer, and multilingual support (Chinese/Russian) further enhance stability and ease of operation for global users.

Technical Specifications
Model NORoller Shutter Door Roll Forming Machine
ConditionNew
The machine itself80*80 square tube heavy frame
Number of molding passes15
Shaft material45# steel (solid shaft, Φ50mm)
Transmission structureGear transmission
Frame thickness16mm wall plate
Hydraulic pump station4kw (with air cooling)
Cutting section motor4kw main motor
Production speed15-16m/min
Control systemIndustrial PLC + frequency control (Delta brand)
Cutting methodPost-forming double-blade shearing
Pull rod35mm galvanized
ReducerType 4 cycloidal series
Operation languageChinese, Russian
Product Gallery
Frequently Asked Questions
Is the electrical system susceptible to moisture damage?
The electrical cabinet features a dust-proof and moisture-resistant design, allowing it to operate normally even within a simple outdoor shelter.
What are the available cutting methods?
Hydraulic Flying Shear
Servo Tracking Flying Shear (Higher precision, faster speed, burr-free cuts)
Can the machine produce stainless steel sheets? What are the requirements for the equipment?
Yes, it can; however, it requires reinforcing the forming frames, increasing the hardness of the rollers, and adjusting the forming process.
Can you provide semi-automatic or fully automatic receiving tables?
Yes, optional configurations include pneumatic receiving, hydraulic receiving, and automatic stackers.
How can issues such as skewed or off-center sheet feeding be resolved?
The equipment is equipped with a hydraulic alignment system or a manually adjustable feed guide mechanism, allowing for easy correction.
Machine alignment and feeding mechanism
