| Categories | Hot Press Furnace |
|---|---|
| Brand Name: | Nuotian |
| Model Number: | NTI-RYL-500T |
| Certification: | CE |
| Place of Origin: | Hunan, China |
| MOQ: | 1 Set |
| Price: | $80000-100000 |
| Payment Terms: | T/T |
| Supply Ability: | 20 Sets/ Month |
| Delivery Time: | 90 Days |
| Packaging Details: | Standard Packing by Sea |
| type: | Resistance Furnace |
| Power control: | SCR |
| video outgoing-inspection: | Provided |
| machinery test report: | Provided |
| core components: | PLC |
| voltage: | 380V |
| dimension(l*w*h): | Customization |
| weight (t): | 2 |
| warranty: | 1 Year |
| key selling points: | Accurate Temperature Control |
| Product Name: | Advanced Ceramic Hot Press Sintering Powder 2200°C Vacuum Treatment Furnace |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Maximum temperature: | 2300 degree celsius |
| Model no.: | NTI-RYL-500T |
| Working area: | Ø620xH500mm |
| Input voltage: | 380v |
| Working atmosphere: | vacuum or inert gas atmosphere |
| Application: | Sic powder hot press sintering |
| Company Info. |
| Zhuzhou Nuotian Electric Heating Technology Co.,Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |


Hot Press Furnace -- Technology Parameter | ||||||||
Production usage | ||||||||
NTI-RYL-20T | NTI-RYL-50T | NTI-RYL-100T | NTI-RYL-200T | NTI-RYL-400T | NTI-RYL-600T | NTI-RYL-800T | ||
Working size | mm | ф160x160 | ф200x300 | ф300x400 | ф400x500 | ф500x600 | ф600x700 | ф700x800 |
Heating type | Graphite resistance | |||||||
Control type | / | SCR control | ||||||
Pressure rise rate | Pa/h | 3 | 5 | 6 | 6 | 6 | 6 | 6 |
IF power | Kw | 40 | 75 | 150 | 250 | 400 | 550 | 700 |
Ultimate vacuum | Pa | 6*10-3 | ||||||
Max.working temperature | ℃ | 2300 | 2300 | 2300 | 2300 | 2300 | 2300 | 2300 |
Pressure | Ton | 20 | 50 | 100 | 200 | 400 | 600 | 800 |
Displacemenet | mm | 0-100 | 0-150 | 0-250 | 0-350 | 0-450 | 0-550 | 0-650 |
Working environment | / | Vacuum or Ar, Nitrogen atmosphere protection(micro positive pressure) | ||||||


|
