| Categories | Nickel Alloy and Super Alloy |
|---|---|
| MOQ: | 1 Ton |
| Price: | US $750-1,150 / Ton |
| Model Number: | DC01(ST12) |
| Grade: | DC01 |
| Number: | 1.0330 |
| Classification: | Non-alloy quality steel |
| Carbon Content: | max 0.12% |
| Manganese Content: | max 0.6% |
| Phosphorus Content: | max 0.045% |
| Sulfur Content: | max 0.045% |
| Tensile Strength: | 270-410 MPa |
| Yield Strength: | 280 MPa |
| Elongation (Lo=80mm): | 28% |
| Elongation (Lo=5.65√So): | 32% |
| Vickers Hardness: | 105 HV |
| Dimensions: | 1220*2440, 1500*3000, 1500*6000, 2000*6000mm |
| Edge Type: | Slit edge |
| Company Info. |
| JIANGSU MITTEL STEEL INDUSTRIAL LIMITED |
| Verified Supplier |
| View Contact Details |
| Product List |
| Grade: | DC01 |
| Number: | 1.0330 |
| Classification: | Non-alloy quality steel |
| Element | Maximum % |
|---|---|
| C (Carbon) | 0.12 |
| Mn (Manganese) | 0.6 |
| P (Phosphorus) | 0.045 |
| S (Sulfur) | 0.045 |
| Property | Value |
|---|---|
| Tensile Strength (Rm) - MPa | 270-410 |
| Minimum Yield Strength (ReH) - MPa | 280 |
| Min. Elongation Lo = 80 mm (%) | 28 |
| Min. Elongation Lo = 5,65 √ So (%) (+A) | 32 |
| Vickers Hardness (HV): (+A) | 105 |
| Region | Standard | Equivalent Grade |
|---|---|---|
| EU EN | DC01 | |
| USA | SAE | 1008, 1010 |
| Germany | DIN, WNr | FeP01, St12 |
| Japan | JIS | SPCC |
| France | AFNOR | C, F12, FeP01 |
| England | BS | CR4, FeP01 |
| China | GB | 08, 08F |
| Russia | GOST | 08kp, 08ps |
| International | ISO | Cr01, CR22 |
|
