0.72 Inch Bar Type TFT Display with 60x160 Resolution and SPI Interface Driving GC9D01

0.72 Inch Bar Type TFT Display with 60x160 Resolution and SPI Interface Driving GC9D01

0.72 Inch Bar Type TFT Display with 60x160 Resolution and SPI Interface Driving GC9D01
0.72 Inch Bar Type TFT Display with 60x160 Resolution and SPI Interface Driving GC9D01
Categories Bar Type TFT
Brand Name: HuaXin
Model Number: HXCM6P2DA001A
Certification: ISO14001/ISO9001/IATF16949
Place of Origin: China
MOQ: 1000
Price: negotiation
Payment Terms: T/T
Supply Ability: 100K per month
Delivery Time: 6weeks~8weeks
Packaging Details: blister+foam box+bubble bag+inside carton+master carton
Display Technology: Bar LCD Display
name: TFT color display
size: 0.72"
resolution: 60(H)RGB x 160(V)
Brightness: 350cd/m2
view angle: free view angle
interface: 4 Line SPI
Contact Now
Company Info.
HuaXin Technology (HK) Co.,Ltd
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

0.72 Inch Bar Type TFT Display with 60x160 Resolution and SPI Interface Driving GC9D01

HX072-0616TBBIG41 Bar Type TFT Display
0.72 inch bar type TFT display with 60*160 dots resolution, SPI interface, GC9D01 driving IC, and 350 cd/m² brightness.
Product Specifications
Part NumberHX072-0616TBBIG41
Display TechnologyTFT Display
Diagonal Screen Size0.72 inch
Active Area6.41mm (H) * 17.09mm (V)
Panel Size8.52mm (H) * 21.695mm (V) * 1.47mm
Brightness350 cd/m²
Resolution60 (H) RGB * 160 (V)
Interface4 Line SPI
View AngleAll Directions
Driving ICGC9D01
Product Images
HX072-0616TBBIG41 TFT display front view HX072-0616TBBIG41 TFT display side view HX072-0616TBBIG41 TFT display close-up HX072-0616TBBIG41 TFT display technical view
Technical Drawing
HX072-0616TBBIG41 technical dimensions drawing
TFT Technology Overview
TFT substrate input and CF substrate input manufacturing process:
TFT and CF substrate input manufacturing flow chart
TFT structure diagram:
TFT display structure diagram
Manufacturer Information
Huaxin Technology (Enshi) Co., LTD
Location: Hubei, Enshi
Founded: 2009
High technology enterprise specializing in research, development, production and sales of LCD, LCM, TFT, backlight, and OLED displays.
Company Advantages
  • Cost-effective factory base located in inland city
  • Advanced equipment ensuring stable quality
  • Fully automated processes for efficiency and quality consistency
  • Professional engineering team with 20+ years LCD experience
  • Custom product design capabilities
Certifications
  • ISO14001 Environmental Management
  • ISO9001/IATF16949 Quality Management
  • SGS LCD Module Certification
Product Portfolio
  • LCD: VA, TN, HTN, STN, FSTN, CSTN and other series
  • LCM: COB, TBA, COG, TP, LED backlight and other series
Company Statistics
  • Registered Capital: 20 million
  • Current Staff: 500+ employees
  • R&D Team: 10% of workforce
  • Quality Control: 15% of workforce
Production Capacity
Product Type20212022202320242025Unit
LCD Production4.59999Thousands of logarithms/Day
LCM Production70150300450450Thousand pieces/Day
Backlight Production100200300500500Thousand pieces/Day
OLED Production1020304050Thousand pieces/Day
Product Applications
  • Car navigation systems & printers
  • Video call systems & advertising displays
  • Automotive & medical devices
  • Fitness equipment & handheld devices
  • Industrial control systems & home appliances
TFT Display Advantages
  • Image Quality: Excellent resolution, sharpness, and color accuracy
  • Response Time: Fast pixel switching capabilities
  • Viewing Angles: Wide viewing angles with minimal color shift
  • Energy Efficiency: Lower power consumption compared to other technologies
  • Size Flexibility: Available in various sizes from small handheld to large panels
  • Backlighting: Compatible with LED backlighting systems
  • Application Range: Suitable for diverse industrial and consumer applications
TFT Display Limitations
  • Limited viewing angles compared to some technologies
  • Limited contrast ratio in certain conditions
  • Backlighting requirements affect power consumption
  • Response time limitations may cause motion blur
  • Limited flexibility in physical form factors
  • Limited color gamut compared to advanced display technologies
