| Categories | Wheel Tractor |
|---|---|
| Place of Origin: | China |
| Brand Name: | JINMA |
| Certification: | EEC, COC, EPA |
| Model Number: | JM204E |
| Type: | Wheel Tractor |
| By wheel: | 4WD |
| Usage: | Farm Tractor |
| Certificate: | EEC |
| Power: | 20hp |
| MOQ: | 1 set |
| Price: | negotiable |
| Packaging Details: | Crate |
| Delivery Time: | within 30-45 days after receipt of payment |
| Payment Terms: | t/t in advance or l/c at sight |
| Supply Ability: | 5000 pieces /month |
| Shipment: | by sea or by train |
MODEL | JINMA-204E | ||
OVERALL DIMENSIONS | L | 3185 mm | |
W | 1440-1460 mm | ||
H | 2530 mm | ||
WHEEL BASE(mm) | 1645 | ||
WHEEL TREAD(mm) | FRONT | 1100 | |
REAR | 1200-1400 | ||
TYRES | 6.00-12 | 8.3-24 | |
RATED TRACTION FORCE (N) | 4800 | ||
PTO SPEED | 540 rpm OR 540/1000 rpm | ||
3 HITCH TYPE | CATEGORY 0 | ||
CLUTCH | DUAL STAGE | ||
SPEED (Km/h) | FORWARD | NORMAL | CREEP |
1.64 | 0.30 | ||
3.24 | 0.60 | ||
5.41 | 1.01 | ||
7.59 | 1.41 | ||
15.00 | 2.79 | ||
25.00 | 4.66 | ||
REVERSE | 1.30 | 0.24 | |
6.02 | 1.12 | ||
ENGINE | MODEL | KM385TE | |
TYPE OF ENGINE | 3 Cylinder Vertical,Water cooled, 4 Stroke, swirl diesel | ||
RATED POWER | 14.7 KW ,20 HP | ||
RATED SPEED | 2350 rpm | ||
After got the complaint from the clients, first need got the
following information:
1. Photos, video and problems description (as more details as
better)
2. Checking the machine’s seal No., Engine No. and the date of
arrived. Asking the clients supply the working hour
3. If it is in the warranty, supply free parts according the
warranty policy; If not, supply necessary technical supply to help
client fix the problem and offer paid parts
4. Ask the part No. according the part catalogue when fixed the
problem and supply the parts
|
