| Categories | Industrial LED High Bay Light |
|---|---|
| Brand Name: | KHJ |
| Model Number: | KT240, KT300, KT360 |
| Certification: | CE,RoHS |
| Place of Origin: | Guangdong, China |
| MOQ: | 1pcs |
| Price: | Negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 400pcs per day |
| Delivery Time: | 3-8 work days |
| Product Name: | Tank Series |
| Working Voltage: | 100-277 VAC, 347-480 VAC,141-391VDC,491-679 VDC |
| Power: | 240W 300W 360W |
| Luminaire Efficacy: | Max:152lm/W |
| Available cable outer diameter: | φ7-φ14(mm) |
| Cable Entries: | 2XM20*1.5 (NPT 3/4”, M25*1.5 are optional) |
| Earthing Protection: | M4 (Internal & external earth bolts) |
| Enclosure Material: | Aluminium |
240W 300W 360W LED Industrial High Bay Light IP66 Tank Series
240W 300W 360W LED High Bay Lights LED Industrial High Bay Light IP66 Tank Series
Highlight: LED High Bay Lights
Features And Benefits:
1. High lumen output LED.
2. Robust aluminum housing and strong tempered glass.
3. Low THD around 10%, less interference.
4. Vibration and shock resistant.
5. Dust proof structure design to avoid dust accumulation.
6. IP66 rated.
Product Differentiation:
| Executive Standard | EN 55015, EN 61547, EN 61000-3-2, EN 61000-3-3, EN 60598-1, EN 60598-2-5, EN 62031, EN 62493, IEC 62321-4, IEC 62321-5, IEC 62321-6, IEC 62321-7-1, IEC 62321-7-2, IEC 62321-8 |
| Certificate | CE, RoHS |
| Ambient temp | -40℃ ≤ Ta ≤ +55℃ |
| Ingress Protection | IP66 |
| Cable entry | M25*1.5(M20*1.5,3/4 NPT for optional) |
Applications:
Industrial LED High Bay Light suitable for industrial areas like power generation, warehouse, factory and more.
Ordering information:
| P/N | Operating Voltage(V) | Luminous Flux(lm) | Power(W) | CRI | Color Temp. | CCT(K) |
| KTK240**CH-P3-E | 100-277 VAC(141-392 VDC) | 33520 | 240 | 70 | Cool white | 5700±300k |
| KTK240**NH-P3-E | 33520 | 70 | Natural white | 5000±300k | ||
| KTK240**NH-P3-E | 33520 | 70 | Natural white | 4000±300k | ||
| KTK240**WM-P3-E | 30168 | 70 | Warm white | 3000±300k | ||
| KTK300**CH-P3-E | 43500 | 300 | 70 | Cool white | 5700±300k | |
| KTK300**NH-P3-E | 43500 | 70 | Natural white | 5000±300k | ||
| KTK300**NH-P3-E | 43500 | 70 | Natural white | 4000±300k | ||
| KTK300**WM-P3-E | 31950 | 70 | Warm white | 3000±300k | ||
| KTK360 ** CH-P3-E | 51120 | 360 | 70 | Cool white | 5700±300k | |
| KTK360 ** NH-P3-E | 51120 | 70 | Natural white | 5000±300k | ||
| KTK360 ** NH-P3-E | 51120 | 70 | Natural white | 4000±300k | ||
| KTK360** WM-P3-E | 46008 | 70 | Warm white | 3000±300k |
Remarks:
1. The first * stands for Operating Voltage including default -100-277VAC,D-347-480VAC ,E-20-30VAC.
2. The second * stands for Candela Distribution including H3V3,H5V5,H6V6.
|
