Name: 8 Channels 8Bit DigitaltoAnalog Converterwith Output Operational Amplifier Integrated Circuit IC
Brand: UCHI
Price: 1 USD

Product Details
Company Profile

8 Channels, 8-Bit Digital-to-Analog Converterwith Output Operational Amplifier Integrated Circuit IC

The SGM5347-8 features 8 channels of 8-bit digital-toanalog converter (DAC) with output amplifiers. Theoutput amplifier provides high current drive capability.The digital data is input via a serial link bus. Only threecontrol lines are required, and cascaded connectionscan be used. The SGM5347-8 provides daisy-chaincapability, which can update multiple SGM5347-8ssimultaneously by using a single serial interface.The SGM5347-8 is available in Green SOIC-16 andTSSOP-16 packages. It operates over an ambienttemperature range of -40℃ to +125℃.

Key Features

● Low Power Consumption (0.5mW/CH)
● Integrating 8 Channels of 8-Bit DAC
● Build-In Analog Output Amplifier:Sink/Source Current with Short Current Control
● Daisy-Chain Operation
● 8 Channels Outputs Update Simultaneously
● Independent Channel Power-Down Function 0.6μA (TYP) ICC for Power-Down Mode
● The Range of D/A Conversion can be IndependentlySet by Separating the Power Supply for MCU Interfaceand Operational Amplifier and the Power Supply forDAC
● Capable of Being Controlled Directly by a 3V MCU
● Power-On Reset: Output Reset to GND
● Serial Data Input: Up to 2.5MHz Operation
● Power Supply Voltage Range: 2.8V to 5.5V
● Available in Green SOIC-16 and TSSOP-16Packages

Applications

High Impedance Sensor
Precision Instrumentation
Photodiode Amplifier
Phase-Locked Loop Filter
High End, Professional Audio
Medical
ATE
DAC Output Amplifier

Pin Configurations

Product Selection Guide

Part Number	Resolution (Bits)	Update Rate (SPS)	Output Channels	Output Voltage Range (V)	Reference	VDD (V)	INL (LSB)	DN (LSB)	Offset Error (mV)	Gain Error (% of FSR)	Gain Drift (ppm/℃)	Output Settling Time (μs)	Operating IQ (μA)	Power-Down IQ (μA)	Operating Temperature Range (℃)	Package	Features
SGM5347-8	8	90K	8	0 ~ VREF	External	2.8~5.5	0.2	0.02	3	0.1	2	7	500	0.6	-40 to +125	SOIC-16,TSSOP-16	8 Channels, 8-Bit DAC with Output Operational Amplifier
SGM5347-10	10	83K	8	0 ~ VREF	External	2.8~5.5	0.8	0.08	3	0.1	2	7	500	0.6	-40 to +125	SOIC-16,TSSOP-16	8 Channels, 10-Bit DAC with Output Operational Amplifier
SGM5347-12	12	77K	8	0 ~ VREF	External	2.8~5.5	3	0.3	3	0.1	2	7	500	0.6	-40 to +125	SOIC-16,TSSOP-16	8 Channels, 12-Bit DAC with Output Operational Amplifier
SGM5348-8	8	200K	8	0 ~ VREF	External	2.8~5.5	0.2	0.02	3	0.1	2	7	500	0.6	-40 to +125	TSSOP-16	8 Channels, 8-Bit DAC with Output Operational Amplifier
SGM5348-10	10	200K	8	0 ~ VREF	External	2.8~5.5	0.8	0.08	3	0.1	2	7	500	0.6	-40 to +125	TSSOP-16	8 Channels, 10-Bit DAC with Output Operational Amplifier
SGM5348-12	12	140K	8	0 ~ VREF	External	2.8~5.5	3	0.3	3	0.1	2	7	500	0.6	-40 to +125	TSSOP-16,TQFN-3×3-16L	8 Channels, 12-Bit DAC with Output Operational Amplifier
SGM5349-16	16	140K	8	0 ~ VREF	External	2.7~5.5	8	0.4	1.5	0.1	2	5	800	1	-40 to +125	TSSOP-16,TQFN-4×4-16L	8 Channels, 16-Bit, SPI Interface, Voltage-Output DAC
SGM5351-16	16	140K	1	0 ~ VREF	External	2.7~5.5	8	0.4	1.5	0.1	2	5	140	0.5	-40 to +125	MSOP-8	16-Bit, Ultra-Low Glitch, Voltage-Output DAC
SGM5352-16	16	140K	4	0 ~ VREFH	External	2.7~5.5	6	0.5	1.5	0.01	2	10	450	0.45	-40 to +125	WLCSP-1.64×1.62-16B,TSSOP-16	16-Bit, 4 Channels, Voltage-Output DAC
SGM5353-16	16	700K	1	0 ~ VREF - 1LSB	External	2.7~5.5	0.15	0.3	0.015	0.0012	0.04	1.5	78		-40 to +125	SOIC-8,TDFN-3×3-8L	16-Bit, Serial Input, Voltage-Output DAC
SGM5355-16	16	140K	1	0 ~ VREF	External	2.7~5.5	6	0.5	1.5	0.05	2	10	108	0.45	-40 to +125	WLCSP-0.82×1.22-6B,MSOP-8	16-Bit, I 2 C Interface, Voltage-Output DAC
SGM71612R8	16	140K	8	0 ~ VCC	Internal/External	2.7~5.5	1.8	<1	0.7	<0.4	1.5	5	800	0.45	-40 to +125	TSSOP-16,TQFN-4×4-16BL,FOCSP-2.6×2.6-16B	8 Channels, 16-Bit, SPI Interface, Voltage-Output DAC

Integrated circuits (ICs) serve as the foundation of modern electronics, offering small size, low power consumption, strong performance and high reliability. They are widely used in consumer electronics, industrial applications, communications, automotive electronics, medical equipment, and aerospace/defense systems.

Electronic components and circuit board applications

Uchi Electronics provides high-performance analog and mixed-signal processing solutions for industrial automation, new energy, automotive, communications, computing, consumer electronics and medical equipment applications.

This solution demonstrates the application of integrated circuits in laptops and desktop computers. For assistance selecting the right product, please contact our technical support team.

8 Channels, 8-Bit Digital-to-Analog Converterwith Output Operational Amplifier Integrated Circuit IC

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	Guangdong Uchi Electronics Co.,Ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Categories	High Power Mosfet
Brand Name:	UCHI
Model Number:	SGM5347-8
Certification:	Completed
Place of Origin:	Dongguan China
MOQ:	1000PCS
Price:	Negotiable
Payment Terms:	T/T,Western Union
Supply Ability:	5000pcs
Delivery Time:	3weeks
Packaging Details:	Standard
VCC:	-0.3V to 6.5V
Input Voltage Range, VIN:	-0.3V to VCC + 0.3V
SOIC-16:	90℃/W
TSSOP-16:	120℃/W
Junction Temperature:	+150℃
Storage Temperature Range:	-65℃ to +150℃
Lead Temperature (Soldering, 10s):	+260℃
HBM:	4000V
CDM:	1000V
