MT2499A 3.5A 4.5V-21V Input 340KHzSynchronous Step-Down Converter

Categories Power Management Chip
Brand Name: AEROSEMI
Model Number: MT2492A
Certification: rohs
Place of Origin: CN
MOQ: 1
Price: consult with
Payment Terms: T/T,Western Union
Supply Ability: 100000
Delivery Time: 5-8days
Packaging Details: T/R
Chip type: DC/DC Converter
operating voltage: 4.5V~21V
Switching Frequency: 340kHz
Static Current (Iq): -
Output Control Terminals: 1
Operating temperature range (°C): -40℃~+85℃@(TA)
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

MT2499A 3.5A 4.5V-21V Input 340KHzSynchronous Step-Down Converter

MT2499A 3.5A 4.5V-21V Input 340KHz Synchronous Step-Down Converter
Product Overview
The MT2499A is a high-efficiency synchronous step-down converter capable of delivering up to 3.5A output current with a wide 4.5V to 21V input voltage range.
Key Features
  • High Efficiency: Up to 94%
  • 340KHz Switching Frequency Operation
  • 3.5A Continuous Output Current
  • No Schottky Diode Required
  • 4.5V to 21V Input Voltage Range
  • 0.925V Reference Voltage
  • Slope Compensated Current Mode Control for Excellent Line and Load Transient Response
  • Integrated Internal Compensation
  • Stable with Low ESR Ceramic Output Capacitors
  • Over Current Protection with Hiccup-Mode
  • Thermal Shutdown Protection
  • Inrush Current Limit and Soft Start
  • Available in ESOP8 Package
  • -40°C to +85°C Operating Temperature Range
Applications
  • Distributed Power Systems
  • Digital Set Top Boxes
  • Flat Panel Television and Monitors
  • Wireless and DSL Modems
  • Notebook Computers
Electrical Parameters
ParameterConditionsMinTypMaxUnit
Input Voltage Range4.521V
Supply Current in OperationVEN=2.0V, VFB=1.1V0.40.6mA
Supply Current in ShutdownVEN =0 or EN = GND1µA
Regulated Feedback VoltageTA = 25°C, 4.5V≤VIN ≤21V0.9000.9250.950V
OVP22V
High-Side Switch On-Resistance75
Low-Side Switch On-Resistance55
MT2499A synchronous step-down converter technical diagram MT2499A application circuit schematic MT2499A performance characteristics graph MT2499A package dimensions and layout
